Jeep Cherokee III (2001-2004) adjustable pedals module Wiring diagrams
This page contains all the electrical diagrams for the component. adjustable pedals module, in which he is found in the car Jeep Cherokee III (2001-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram adjustable pedals module (1 of 5)
4.0L
4.7L
ADJUSTABLE PEDALS MODULE
AUTOMATIC DAY/NIGHT MIRROR
BACK UP LAMP
BLK WIRE
BRN WIRE
FUSE 20
HOT IN RUN
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEFT REAR LAMP ASSEMBLY
PARK/NEUTRAL POSITION SWITCH (LOWER LEFT SIDE OF TRANSMISSION)
PNK WIRE
RIGHT REAR LAMP ASSEMBLY
TAN WIRE
TRAILER TOW CONNECTOR
TRANSMISSION SOLENOID/TRS ASSEMBLY (ON TRANSMISSION VALVE BODY)
VIO WIRE
WHT WIRE
Go to component -> Back-up lamps circuit -> ADJUSTABLE PEDALS MODULE
Wiring diagram adjustable pedals module (2 of 5)
10 8 PCI BUS FLASH ENABLE
15 17 PCI BUS FLASH ENABLE
ADJUSTABLE PEDALS MODULE
AIR BAG CONTROL MODULE (BELOW CENTER FLOOR CONSOLE, NEAR PARK BRAKE)
AUTOMATIC ZONE CONTROL MODULE
BLK/LT GRN WIRE
BLK/ORG WIRE
BLK/PNK WIRE
BODY CONTROL MODULE (ON LEFT END OF DASH, ATTACHED TO JUNCTION BLOCK)
COMPACT DISC CHANGER (PREMIUM)
DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH, NEAR STEERING COLUMN)
DIAGNOSTIC JUNCTION PORT (AT BOTTOM OF STEERING COLUMN)
DRIVER DOOR MODULE (BEHIND LEFT FRONT DOOR PANEL)
FUSE 17
HOT AT ALL TIMES
INSTRUMENT CLUSTER
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LT GRN WIRE
LT GRN/DK GRN WIRE
PASSENGER DOOR MODULE (BEHIND RIGHT FRONT DOOR PANEL)
PCI BUS
PNK SCI TRANSMIT WIRE
PNK WIRE
PNK/RED WIRE
POWER AMPLIFIER (PREMIUM) (UNDER PASSENGER SIDE REAR SEAT CUSHION)
POWERTRAIN CONTROL MODULE (ON RIGHT SIDE OF FIREWALL)
RADIO
RAIN SENSOR (W/ AUTOWIPE)
SCI RECEIVE
SEAT MODULE (W/ MEMORY SEATS) (UNDER FRONT OF DRIVER'S SEAT)
SENTRY KEY IMMOBILIZER MODULE (NEAR IGNITION LOCK CYLINDER HOUSING)
TRANSMISSION CONTROL MODULE (W/ 4.7L ENGINE) (ON RIGHT INNER FENDER)
VEHICLE INFORMATION CENTER
VIO/ORG WIRE
VIO/YEL WIRE
YEL/VIO WIRE
YEL/VIO/BLK WIRE
YEL/VIO/BRN WIRE
YEL/VIO/DK BLU WIRE
YEL/VIO/DK GRN WIRE
YEL/VIO/GRY WIRE
YEL/VIO/ORG WIRE
YEL/VIO/RED WIRE
YEL/VIO/WHT WIRE
Go to component -> Computer data lines -> ADJUSTABLE PEDALS MODULE
Wiring diagram adjustable pedals module (3 of 5)
ADJUSTABLE PEDALS MODULE
AUTOMATIC DAY/NIGHT
BASE
BLK WIRE
CENTER HIGH MOUNTED STOP LAMP
CONNECTOR, ABOVE LEFT REAR WHEEL HOUSING)
DRIVER POWER SEAT SWITCH
DRIVER REAR POWER WINDOW SWITCH
EXCEPT BASE
FUEL PUMP MODULE
LEFT LIFTGATE AJAR SWITCH
LEFT REAR DOOR POWER LOCK MOTOR/ AJAR SWITCH
LEFT REAR LAMP ASSEMBLY
LICENSE LAMP 1
LICENSE LAMP 2
LIFTGATE FLIP-UP AJAR SWITCH
LIFTGATE FLIP-UP RELEASE SOLENOID
MIRROR
ORG/ WIRE
OTHER
RAIN SENSOR
REAR WINDOW DEFOGGER
REAR WIPER MOTOR
RIGHT LIFTGATE AJAR SWITCH
SUN ROOF
SUN ROOF CONTROL MODULE
SUN ROOF SWITCH
SUN-ROOF MOTOR
TRAILER TOW BRAKE LAMP RELAY
TRAILER TOW CONNECTOR
TRAILER TOW LEFT TURN RELAY
TRAILER TOW RIGHT TURN RELAY
VEHICLE VEHICLE INFORMATION CENTER CENTER
Go to component -> Ground distribution circuit (2 of 4) -> ADJUSTABLE PEDALS MODULE
Wiring diagram adjustable pedals module (4 of 5)
ADJUSTABLE PEDALS MODULE
AIR BAG CONTROL MODULE
BASE
BASE PREMIUM
BLK WIRE
BRAKE LAMP SWITCH
DRIVER CYLINDER LOCK SWITCH
DRIVER DOOR LOCK/MOTOR AJAR SWITCH
DRIVER DOOR MODULE
ELECTRIC BRAKE
OTHER
PASSENGER DOOR LOCK/MOTOR AJAR SWITCH
PASSENGER DOOR MODULE
PASSENGER LUMBAR SWITCH
PASSENGER POWER SEAT SWITCH
PASSENGER REAR POWER WINDOW SWITCH
PNK WIRE
POWER AMPLIFIER
RADIO
REAR POWER OUTLET
RIGHT REAR DOOR POWER LOCK MOTOR/ AJAR SWITCH
RIGHT REAR LAMP ASSEMBLY
Go to component -> Ground distribution circuit (3 of 4) -> ADJUSTABLE PEDALS MODULE
Wiring diagram adjustable pedals module (5 of 5)
