Jeep Cherokee III (2001-2004) 1 2 3 4 memory switch rtn memory switch set memory position 1 memory position 2 Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 SEAT HORIZ FWD SENS 1 2 3 4 MEMORY SWITCH RTN MEMORY SWITCH SET MEMORY POSITION 1 MEMORY POSITION 2 BACK UP SEAT FRNT BACK UP SEAT HORIZ SEAT REAR BLK WIRE BLK/ORG WIRE BLK/VIO WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE CIRCUIT BREAKER 2 COMPUTER DATA LINES DK BLU WIRE DK GRN/WHT WIRE DK GRN/YEL WIRE DRIVER POWER SEAT SWITCH DRIVER SEAT FRONT RISER MOTOR SENSOR (UNDER LEFT SEAT) DRIVER SEAT FRONT VERTICAL MOTOR DRIVER SEAT HORIZONTAL MOTOR SENSOR (UNDER LEFT SEAT) DRIVER SEAT REAR RISER MOTOR SENSOR (UNDER LEFT SEAT) DRIVER SEAT REAR VERTICAL MOTOR DRIVER SEAT RECLINER MOTOR DRIVER SEAT HORIZONTAL MOTOR DRIVER SEAT RECLINER MOTOR SENSOR (UNDER LEFT SEAT) DRIVER'S DOOR MODULE (IN DRIVER'S DOOR) FUSE 12 FUSED B+ 4 9 GROUND PCI BUS FWD DN GRN WIRE GROUND PCI BUS GRY WIRE GRY/LT BLU WIRE GRY/LT GRN WIRE GRY/WHT WIRE HOT AT ALL TIMES JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) LT BLU WIRE LT BLU/BLK WIRE LT BLU/RED WIRE LT GRN WIRE LT LT MEMORY 1 MEMORY 2 MEMORY SET MEMORY SET SWITCH ORG/ WIRE ORG/WHT WIRE POWER DISTRIBUTION CENTER (NEXT TO BATTERY) RECLINE RECLINER DWN DRVR RECLINER UP DRVR SEAT HORIZ REAR DRVR RED WIRE RED/BLK WIRE RED/BRN WIRE RED/GRY WIRE RED/LT BLU WIRE RED/LT GRN WIRE RED/WHT WIRE RED/YEL WIRE SEAT FRNT DWN SENS SEAT REAR DWN SENS RECLINER POS SIG FRNT RISER POS SIG SEAT HORIZ FWD DRVR FUSED B+ R SEAT HTR B+ GND SEAT MODULE (UNDER DRIVER'S SEAT) SEAT SWITCH B+ L SEAT HTR GND R SEAT HTR GND SEATS (HEATED) SEATS (HEATED) SEATS (HEATED) VIO WIRE VIO/RED WIRE WHT WIRE YEL WIRE YEL/DK BLU WIRE YEL/LT BLU WIRE YEL/LT GRN WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE
