Jeep Cherokee II facelift (1997-2001) vehicle speed control servo washer fluid level switch Wiring diagram
This page shows the only wiring diagram for the component.vehicle speed control servo washer fluid level switch, which is found in the car Jeep Cherokee II facelift (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vehicle speed control servo washer fluid level switch (1 of 1)
2.5L 4.0L
A/T
BATTERY
BLEND DOOR ACTUATOR POWER OUTLET CIGAR LIGHTER HVAC UNIT COMPASS
BLK WIRE
BLK/TAN WIRE
BLK/WHT WIRE
BRN/LT BLU WIRE
CIGAR LIGHTER RELAY PASSENGER POWER MIRROR
CONTROLLER ANTI-LOCK BRAKE
CONTROLLER ANTI-LOCK BRAKE RELAY
DATA LINK CONNECTOR
DAYTIME RUNNING LAMP MODULE
DOME LAMP SWITCH OVERHEAD MODULE
EXTENDED IDLE SWITCH
FOG LAMP RELAY
FROM
FRONT FOG LAMP SWITCH REAR WIPER/ WASHER SWITCH COMBIN- ATION FLASHER
FULL OPTIONS
JUNCTION BLOCK
LEFT HEAD- LAMP
LEFT PARK/TURN SIGNAL LAMP 1 LEFT PARK/TURN SIGNAL LAMP 2
LEFT POWER SEAT SWITCH
M/T
OTHERS
OVERHEAD CONSOLE
OXYGEN SENSOR-1/1 UPSTREAM
OXYGEN SENSOR-1/2 DOWNSTREAM
PASSENGER FRONT POWER LOCK/ WINDOW SWITCH
POWER DISTRIBUTION CENTER
POWERTRAIN CONTROL MODULE
RADIATOR FAN MOTOR
REAR OF ENGINE COMPT)
REAR WASHER PUMP MOTOR
REAR WINDOW DEFOGGER SWITCH SEAT BELT SWITCH
RIGHT PARK/TURN SIGNAL LAMP 1 LEFT FOG LAMP
RIGHT PARK/TURN SIGNAL LAMP 2 RIGHT FOG LAMP RIGHT HEAD- LAMP
RIGHT POWER SEAT SWITCH
TRANSFER CASE SWITCH
UNDER- HOOD LAMP MERCURY SWITCH
VEHICLE SPEED CONTROL SERVO WASHER FLUID LEVEL SWITCH
W/ POLICE PACKAGE W/O POLICE PACKAGE
WASHER FLUID LEVEL SWITCH
WINDSHIELD WASHER PUMP MOTOR
Go to component -> Ground distribution circuit (1 of 2) -> VEHICLE SPEED CONTROL SERVO WASHER FLUID LEVEL SWITCH
