Jeep Cherokee II facelift (1997-2001) to right rear turning lamp Wiring diagram
This page shows the only wiring diagram for the component.to right rear turning lamp, which is found in the car Jeep Cherokee II facelift (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram to right rear turning lamp (1 of 1)
4.0L
4.7L
BLK WIRE
BLK/YEL WIRE
BODY CONTROL MODULE PARK LAMP RELAY CONTROL
BRAKE LAMP SWITCH
BRN/RED WIRE
CIGAR LIGHTER RELAY
COMBINATION FLASHER RIGHT TURN SIGNAL
CONTROLLER, ANTI-LOCK BRAKES
DK GRN/RED WIRE
DK GRN/YEL WIRE
FUSE 23 FUSE 18
FUSE 6
HOT AT ALL TIMES
JUNCTION BLOCK
LEFT TURN SIGNAL
LT BLU WIRE
ORG/WHT WIRE
PARK LAMP RELAY
PARK/ NEUTRAL POSITION SWITCH B/U LAMP FEED
PNK/DK BLU WIRE
RED WIRE
RED/YEL WIRE
TO CENTER HIGH MTD. STOP LAMP
TO LEFT REAR TAIL- LAMP)
TO LEFT REAR TURNING LAMP
TO RIGHT REAR TURNING LAMP
TRAILER BRAKE PROVISION
TRAILER TOW BRAKE LAMP RELAY
TRAILER TOW CIRCUIT BREAKER C/B
TRAILER TOW CONNECTOR
TRAILER TOW LEFT TURN RELAY
TRAILER TOW RIGHT TURN RELAY
TRANSMISSION SOLENOID/ TRS ASSEMBLY B/U LAMP FEED
VIO/BLK WIRE
WHT/TAN WIRE
Go to component -> Trailer tow circuit -> TO RIGHT REAR TURNING LAMP
