Jeep Cherokee II facelift (1997-2001) sci receive pci bus Wiring diagrams
This page contains all the electrical diagrams for the component. sci receive pci bus, in which he is found in the car Jeep Cherokee II facelift (1997-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram sci receive pci bus (1 of 2)
2 6 7 DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH, NEAR STEERING COLUMN)
A/C PRES SIG
A/C SYSTEM
ASD RELAY CTRL VAC SOL CTRL VENT SOL CTRL
BATTERY TEMPERATURE SENSOR (BELOW BATTERY TRAY)
BLK WIRE
BLK/DK GRN WIRE
BLK/LT BLU WIRE
BRAKE SW SENS GEN SOURCE FUEL LEV SENSOR SCI TRANSMIT
BRN WIRE
CALIF EX. CALIF.
CHECK ENGINE IND
CRUISE CONTROL SYSTEM
DK BLU WIRE
DK BLU/ORG WIRE
DK BLU/YEL WIRE
DK GRN WIRE
DK GRN/LT GRN WIRE
DUTY CYCLE EVAP/PURGE SOLENOID
EX CALIF CALIF
FUEL PMP RLY EVAP EMIS
FUSE 17
FUSE 21
GRN WIRE
GRY WIRE
HEATER RELAY DOWN- STREAM (CALI- FORNIA)
HEATER RELAY UP- STREAM (CALI- FORNIA)
HOT AT ALL TIMES
HOT IN START OR RUN
INSTRUMENT CLUSTER
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEAK DETECTION PUMP (BELOW AIR CLEANER HOUSING)
LT BLU WIRE
LT BLU/RED WIRE
LT BLU/YEL WIRE
LT GRN/DK GRN WIRE
LT GRN/RED WIRE
NCA WIRE
ORG/ WIRE
ORG/BLK WIRE
ORG/DK GRN (OR VIO/ORG) WIRE
ORG/DK GRN (OR VIO/WHT) WIRE
ORG/DK GRN WIRE
ORG/PNK WIRE
ORG/YEL WIRE
OVERDRIVE SWITCH
OXYGEN SENSOR 2/1 UPSTREAM (CALIFORNIA) (IN EXHAUST MANIFOLD REAR OUTLET)
OXYGEN SENSOR 2/2 DOWNSTREAM (CALIFORNIA) (OUTLET OF REAR MINI CONVERTER)
PCI BUS
PNK WIRE
PNK/BLK WIRE
PNK/WHT WIRE
POWER DISTRIBUTION CENTER (NEXT TO BATTERY)
POWERTRAIN CONTROL MODULE (ON RIGHT SIDE OF FIREWALL)
RED/LT GRN WIRE
SCI RECEIVE PCI BUS
SENSORS
SHIFT INTERLOCK SYSTEM
SPD CTRL SW
TAN/RED WIRE
TAN/WHT WIRE
VIO WIRE
VIO/LT GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/DK GRN WIRE
WHT/PNK WIRE
YEL/VIO WIRE
YEL/VIO/GRY WIRE
YEL/VIO/RED WIRE
Go to component -> Wiring diagram engine performance 4.0ls (3 of 3) -> SCI RECEIVE PCI BUS
Wiring diagram sci receive pci bus (2 of 2)
2 6 7 DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH, NEAR STEERING COLUMN)
A/C PRES SIG
A/C SYSTEM
ASD RELAY CTRL VAC SOL CTRL VENT SOL CTRL
BATTERY TEMPERATURE SENSOR (BELOW BATTERY TRAY)
BLK WIRE
BLK/DK GRN WIRE
BLK/LT BLU WIRE
BRAKE SW SENS GEN SOURCE FUEL LEV SENSOR SCI TRANSMIT
BRN WIRE
CALIF EX. CALIF.
CHARGING SYSTEM
CHECK ENGINE IND
CRUISE CONTROL SYSTEM
DK BLU WIRE
DK BLU/ORG WIRE
DK BLU/YEL WIRE
DK GRN WIRE
DK GRN/LT GRN WIRE
DUTY CYCLE EVAP/PURGE SOLENOID
FUEL PMP RLY EVAP EMIS
FUSE 17
FUSE 21
GRN WIRE
GRY WIRE
GRY/BLK WIRE
HEATER RELAY DOWN- STREAM (CALI- FORNIA)
HEATER RELAY UP- STREAM (CALI- FORNIA)
HOT AT ALL TIMES
HOT IN START OR RUN
INSTRUMENT CLUSTER
JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH)
LEAK DETECTION PUMP (BELOW AIR CLEANER HOUSING)
LT BLU WIRE
LT BLU/RED WIRE
LT BLU/YEL WIRE
LT GRN/DK GRN WIRE
LT GRN/RED WIRE
NCA WIRE
ORG/ WIRE
ORG/DK GRN (OR VIO/ORG) WIRE
ORG/DK GRN (OR VIO/WHT) WIRE
ORG/DK GRN WIRE
ORG/PNK WIRE
ORG/RED WIRE
ORG/YEL WIRE
OXYGEN SENSOR 2/1 UPSTREAM (CALIFORNIA) (BELOW RIGHT EXHAUST MANIFOLD)
OXYGEN SENSOR 2/2 DOWNSTREAM (CALIFORNIA) (OUTLET OF RIGHT MINI CONVERTER)
PCI BUS
PNK WIRE
PNK/BLK WIRE
PNK/WHT WIRE
POWER DISTRIBUTION CENTER (NEXT TO BATTERY)
POWERTRAIN CONTROL MODULE (ON RIGHT SIDE OF FIREWALL)
RED/LT GRN WIRE
SCI RECEIVE PCI BUS
SHIFT INTERLOCK SYSTEM
SPD CTRL SW
TAN/RED WIRE
TAN/WHT WIRE
TRANSMISSION CONTROL MODULE (ON RIGHT INNER FENDER)
VIO WIRE
VIO/LT GRN WIRE
VIO/ORG WIRE
VIO/WHT WIRE
WHT WIRE
WHT/DK GRN WIRE
WHT/PNK WIRE
YEL/DK GRN WIRE
YEL/VIO WIRE
YEL/VIO/GRY WIRE
YEL/VIO/RED WIRE
Go to component -> Wiring diagram engine performance 4.7ls (3 of 3) -> SCI RECEIVE PCI BUS
