Jeep Cherokee II facelift (1997-2001) right rear lighting module Wiring diagrams
This page contains all the electrical diagrams for the component. right rear lighting module, in which he is found in the car Jeep Cherokee II facelift (1997-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
right rear lighting module wiring diagram (1 of 3)
Go to component -> Back-up lamps circuit -> RIGHT REAR LIGHTING MODULE
right rear lighting module wiring diagram (2 of 3)
BLK WIRE
BLK/ YEL WIRE
BLK/YEL WIRE
BODY CONTROL MODULE PARK LAMP RELAY
BRN/RED WIRE
CENTER HIGH MOUNTED STOP LAMP
COMBINATION FLASHER
COMBINATION FLASHER SWITCH GROUND
CONTROLLER ANTI-LOCK BRAKE BRAKE LAMP EWITCH
DR BLU/ WIRE
DR GRN/ RED WIRE
DR GRN/ WIRE
DR GRN/RED WIRE
FUSE 20
FUSE 23
FUSE 4
FUSE 6
FUSED
FUSED IGNITION SWITCH OUTPUT
HOT AT ALL TIMES
HOT IN ON AND RUN
INSTRUMENT PANEL
JUNCTION BLOCK
LEFT FRONT LIGHTING MODULE
LEFT FRONT MARKER LAMP
LEFT FRONT PARK LAMP
LEFT FRONT PARK/ TURN LAMP
LEFT REAR LIGHTING MODULE
LEFT REAR TAIL/ STOP LAMP
LEFT REAR TAILLAMP
LEFT REAR TURN LAMP
LEFT TURN INDI- CATOR
LEFT TURN SIGNAL
LEFT TURN SIGNAL RIGHT TURN SIGNAL
LEFT TURN SWITCH SENSOR RIGHT TURN SWITCH SENSOR
LICENSE LAMP 1
LICENSE LAMP 2
LT BLU WIRE
LT GRN WIRE
MULTI- FUNCTION SWITCH
OUTPUT
PARK LAMP RELAY
PARK LAMP RELAY CONTROL
PNK WIRE
PNK/ DR BLU WIRE
RED WIRE
RIGHT FRONT LIGHTING MODULE
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK LAMP
RIGHT FRONT PARK/ TURN LAMP
RIGHT REAR LIGHTING MODULE
RIGHT REAR TAIL/ STOP LAMP
RIGHT REAR TURN LAMP
RIGHT TURN SIGNAL
TAN WIRE
TAN/LT GRN WIRE
TO TRAILER TOW BRAKE LAMP RELAY
TO TRAILER TOW LEFT TURN RELAY
TO TRAILER TOW RIGHT TURN RELAY
W/REAR POWER OUTLET
WHT WIRE
WHT/TAN WIRE
YEL WIRE
Go to component -> Exterior lamps & trailer connector circuit -> RIGHT REAR LIGHTING MODULE
right rear lighting module wiring diagram (3 of 3)
BASE
BASE PREMIUM
BLK WIRE
BRAKE LAMP SWITCH
DRIVER CYLINDER LOCK SWITCH
DRIVER DOOR
DRIVER DOOR LOCK/MOTOR AJAR SWITCH
DRIVER DOOR MODULE
OTHER
PASSENGER DOOR LOCK/MOTOR AJAR SWITCH
PASSENGER DOOR MODULE
PASSENGER DOOR)
PASSENGER LUMBAR SWITCH
PASSENGER POWER SEAT SWITCH
PASSENGER REAR DOOR LOCK/MOTOR AJAR SWITCH
PASSENGER REAR POWER WINDOW SWITCH
POWER AMPLIFIER
POWER SEATS
RADIO
REAR POWER OUTLET
RIGHT REAR LIGHTING MODULE
W/ REAR POWER OUTLET W/O REAR POWER OUTLET
Go to component -> Ground distribution circuit (2 of 4) -> RIGHT REAR LIGHTING MODULE
