Jeep Cherokee II facelift (1997-2001) liftgate flip-up push button switch Wiring diagram

21 23 25 10 LIFTGATE AJAR LR DOOR AJAR 7 15 RR DOOR AJAR PCI BUS BLK WIRE BODY CONTROL MODULE COMPUTER DATA LINES SYSTEM DIAGNOSTIC JUNCTION PORT (AT BOTTOM OF STEERING COLUMN) FUSE 12 FUSE 8 FUSED B (+) GROUND HOT AT ALL TIMES JUNCTION BLOCK LEFT FRONT DOOR CYLINDER SWITCH LEFT FRONT DOOR LOCK MOTOR/ AJAR SWITCH LEFT FRONT DOOR MODULE LEFT LIFTGATE AJAR SWITCH LF AJAR SW LF KEY CYL SW SENSE LF LOCK OUT LF UNLOCK OUT LIFTGATE FLIP-UP AJAR SWITCH LIFTGATE FLIP-UP PUSH BUTTON SWITCH LIFTGATE LOCK MOTOR/ LIMIT SWITCH LOCK OUT LT BLU WIRE LT GRN/ORG WIRE NEAR LEFT "B" PILLAR) ORG/ WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/PNK WIRE ORG/VIO WIRE ORG/WHT WIRE PCI BUS PNK PNK WIRE PNK WIRE PNK/BLK WIRE PNK/VIO WIRE POWER DISTRIBUTION CENTER RED WIRE RF AJAR SW RIGHT FRONT DOOR LOCK MOTOR/ AJAR SWITCH RIGHT FRONT DOOR MODULE RIGHT LIFTGATE AJAR SWITCH RIGHT REAR DOOR LOCK MOTOR/ AJAR SWITCH TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/ORG WIRE TAN/RED WIRE TAN/YEL WIRE UNLOCK OUT VIO WIRE YEL WIRE YEL/VIO /GRY WIRE YEL/VIO WIRE YEL/VIO/BRN WIRE YEL/VIO/WHT WIRE
