Jeep Cherokee II facelift (1997-2001) left front lighting module washer fluid level switch Wiring diagram
This page shows the only wiring diagram for the component.left front lighting module washer fluid level switch, which is found in the car Jeep Cherokee II facelift (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front lighting module washer fluid level switch (1 of 1)
4.0L
4.7L
A/C COMPRESSOR CLUTCH
A/C LOW PRESSURE CYCLE CLUTCH SWITCH VEHICLE SPEED CONTROL SERVO
AIRBAG CONTROL MODULE
BATTERY
BLK WIRE
BLK/ORG WIRE
BLK/PNK WIRE
BLK/RED WIRE
BLK/TAN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
CONTROLLER ANTI-LOCK BRAKE
COOLANT LEVEL SENSOR HORN 2
DATA LINK CONNECTOR
DOWNSTREAM 1/2 OXYGEN SENSOR
DOWNSTREAM 2/2 OXYGEN SENSOR UPSTREAM 2/1 OXYGEN SENSOR
HORN 1
LEFT FOG LAMP
LEFT FRONT LIGHTING MODULE WASHER FLUID LEVEL SWITCH
POWERTRAIN CONTROL MODULE
PRESSURE TRANSDUCER
RADIATOR FAN MOTOR
RADIATOR FAN RELAY
REAR WASHER PUMP MOTOR
RIGHT FOG LAMP
RIGHT FRONT LIGHTING MODULE
TRANSFER CASE SWITCH
TRANSMISSION CONTROL MODULE
UNDER- HOOD LAMP
UPSTREAM 1/1 OXYGEN SENSOR
WIND- SHIELD WIPER MOTOR WINDSHIELD WASHER PUMP
Go to component -> Ground distribution circuit (3 of 4) -> LEFT FRONT LIGHTING MODULE WASHER FLUID LEVEL SWITCH
