Jeep Cherokee II facelift (1997-2001) driver door module passenger door module Wiring diagram
This page shows the only wiring diagram for the component.driver door module passenger door module, which is found in the car Jeep Cherokee II facelift (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver door module passenger door module (1 of 1)
4.0L 4.7L
AIRBAG CONTROL MODULE
AUTOMATIC ZONE CONTROL MODULE
BLK/ORG WIRE
BODY CONTROL MODULE FUSE 7
COMBINATION FLASHER
CONTROLLER ANTI-LOCK BRAKE
DK BLU/PNK WIRE
DK BLU/YEL WIRE
DRIVER DOOR MODULE PASSENGER DOOR MODULE
DRIVER HEATED SEAT SWITCH
ENGINE STARTER MOTOR RELAY
FROM FUSE 12 (PDC) (DIAGRAM 1 OF 3)
FROM FUSE 8 (DIAGRAM 2 OF 3)
FROM IGNITION SWITCH (DIAGRAM 2 OF 3)
FRONT POWER OUTLET
FUSE 18
FUSE 19
FUSE 20
FUSE 31
FUSE 33
FUSE 5
FUSE 9
JUNCTION BLOCK
MANUAL TEMPERATURE CONTROL
NCA WIRE
ORG/WHT WIRE
PARK/ NEUTRAL POSITION SWITCH TRANSMISSION SOLENOID/ TRS ASSEMBLY
PASSENGER HEATED SEAT SWITCH
PNK WIRE
PNK/ DK GRN WIRE
PNK/RED WIRE
POWER AMPLIFIER
POWER CONNECTOR
POWER DISTRIBUTION CENTER
RADIO
REAR POWER OUTLET
RED/WHT WIRE
TAN/BLK WIRE
TAN/BLU WIRE
TEMPERATURE VALVE ACTUATOR
TRAILER TOW BRAKE LAMP RELAY
TRANSMISSION CONTROL MODULE (4.7L ONLY)
UNDERHOOD LAMP
VIO WIRE
W/ AUTO A/C
W/ MANUAL A/C
WHT PNK/ WIRE
WHT/PNK WIRE
WHT/TAN WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (3 of 3) -> DRIVER DOOR MODULE PASSENGER DOOR MODULE
