Jeep Cherokee II facelift (1997-2001) cargo lamp and switch Wiring diagram
This page shows the only wiring diagram for the component.cargo lamp and switch, which is found in the car Jeep Cherokee II facelift (1997-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cargo lamp and switch (1 of 1)
A/C HEATER CONTROL
BASE OR POLICE OPTION
BLK WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BRIGHT OFF
CARGO LAMP AND SWITCH
DIMMER
DOME LAMP
DOME LAMP/ SWITCH OR COMPASS
DOME SWITCH
EXTENDED IDLE SWITCH (W/ POLICE PACKAGE)
EXTERIOR LIGHTS
FRONT FOG LAMP SWITCH (W/O POLICE PACKAGE)
FULL OR MIDLINE
FUSE 16
GLOVE BOX LAMP AND SWITCH
GRY/BLK WIRE
HEAD
HEADLAMP SWITCH
HEADLIGHTS SYSTEM (HEADLAMP DELAY MODULE)
HOT AT ALL TIMES
HOT AT ALL TIMES HEADLAMP SWITCH
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM PNK WIRE
JUNCTION BLOCK (BEHIND RIGHT KICK PANEL)
JUNCTION BLOCK (BEHIND RIGHT KICK PANEL) FUSE 6
LEFT COURTESY LAMP RIGHT COURTESY LAMP
LEFT FRONT DOOR JAMB SWITCH LEFT REAR DOOR JAMB SWITCH
LEFT VISOR/ VANITY LAMP
LIFTGATE SWITCH
OFF
ON OFF
ORG/ WIRE
PARK
PNK PNK WIRE
PNK WIRE
POWER DISTRIBUTION CENTER (ON RIGHT SIDE OF ENGINE COMPT, ON INNER FENDER PANEL)
RADIO
REAR WINDOW DEFOGGER SWITCH
REAR WIPER/ WASHER SWITCH
RIGHT FRONT DOOR JAMB SWITCH
RIGHT REAR DOOR JAMB SWITCH
RIGHT VISOR/ VANITY LAMP
TAN WIRE
TRANSFER CASE SWITCH
UNDERHOOD LAMP/ MERCURY SWITCH
YEL WIRE
Go to component -> Interior light circuit -> CARGO LAMP AND SWITCH
