Jeep Cherokee II facelift (1997-2001) 15 17 pci bus sci receive Wiring diagram

15 17 PCI BUS SCI RECEIVE 30 29 27 PCI BUS SCI RECEIVE SCI TRANSMIT AIRBAG CONTROL MODULE (BELOW CENTER FLOOR CONSOLE, NEAR BRAKE) AUTOMATIC ZONE CONTROL MODULE BLK/ORG WIRE BODY CONTROL MODULE (LEFT END OF DASH, ATTACHED TO J/B) BRN WIRE CONROLLER ANTI-LOCK BRAKE (LEFT SIDE OF ENGINE COMPT) DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH, NEAR STEERING COLUMN) DIAGNOSTIC JUNCTION PORT (AT BOTTOM OF STEERING COLUMN) DK BLU WIRE DK GRN WIRE DRIVER DOOR MODULE (IN DOOR) FUSE 17 GRY WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) LT GRN WIRE LT GRN/DK BLU WIRE LT GRN/DK GRN WIRE NOT USED ORG/ WIRE PASSENGER DOOR MODULE (IN DOOR) PCI BUS PNK 7 46 43 SCI TRANSMIT SCI RECEIVE PCI BUS WIRE PNK WIRE PNK/RED WIRE POWERTRAIN CONTROL MODULE (RIGHT SIDE OF FIREWALL) RADIO RED WIRE SEAT MODULE (UNDER SEAT) SENTRY KEY IMMOBILIZER MODULE (NEAR IGNITION LOCK CYLINDER HOUSING) TRANSMISSION CONTROL MODULE (ON RIGHT INNER FENDER) VEHICLE INFORMATION CENTER VIO WIRE VIO/ORG WIRE WHT WIRE YEL WIRE YEL/VIO WIRE YEL/VIO/BLK WIRE YEL/VIO/DK BLU WIRE YEL/VIO/DK GRN WIRE YEL/VIO/ORG WIRE YEL/VIO/RED WIRE YEL/VIO/WHT WIRE
