Jeep Cherokee II (1984-1996) Warning system circuits

AUTO BATTERY BLK WIRE BLK/LT BLU WIRE BLU WIRE CHIME MODULE (IN CONVENIENCE CENTER) DK BLU WIRE DK BLU/RED WIRE DOOR LOCK INHIBIT FUSE 19 FUSE 8 FUSE PANEL GROUND HEADLAMP SWITCH VEHICLE INFORMATION CENTER (LOWER PART OF CENTER CONSOLE) HOT AT ALL TIMES HOT IN RUN IGNITION INSTRUMENT CLUSTER INSTRUMENT PANEL DIMMING/DRL MODULE (LEFT OF STEERING COLUMN) KEY-IN IGNITION SWITCH LEFT FRONT DOOR JAMB SWITCH LIGHTS-ON KEY-IN INPUT LO PARK LO/FOG LT BLU WIRE LT GRN/RED WIRE OFF POWER DOOR LOCK RELAY (IN RELAY CENTER) RED/WHT WIRE SEAT BELT INDICATOR SEAT BELT SW INPUT SEAT BELT SWITCH (IN BUCKLE) SEAT/BELT IND CTRL TONE SIG YEL/BLK WIRE YEL/DK GRN WIRE
