Radio circuits for Jeep Cherokee II (1984-1996)

ANTENNA MAST ANTENNA INPUT BLK WIRE BRN/LT BLU WIRE BRN/RED WIRE BRN/YEL WIRE DIM BRIGHT DK BLU WIRE DK BLU/ORG WIRE DK BLU/RED WIRE DK BLU/WHT WIRE DK GRN WIRE FUSE 15 FUSE 19 FUSE 2 FUSE 9 FUSE PANEL HEAD OFF PARK HEADLAMP SWITCH HOT AT ALL TIMES HOT IN ACC OR RUN L.C.D. ILLUMINATION RELAY (IN RELAY CENTER) LEFT FRONT DOOR SPEAKER LEFT INSTRUMENT PANEL SPEAKER LEFT LIFTGATE SPEAKER LT BLU/RED WIRE ORG/ WIRE ORG/BLK WIRE PNK WIRE RADIO RADIO GROUND RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT INSTRUMENT PANEL SPEAKER RIGHT LIFTGATE SPEAKER VIO WIRE VIO/WHT WIRE WARNING SYSTEMS (CHIME MODULE) WHT WIRE YEL WIRE
