Jeep Cherokee II (1984-1996) Headlamps/fog lamps circuit

AUTO AUTO HEADLAMP LIGHT SENSOR BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN/RED WIRE CHIME MODULE (IN CONVENIENCE CENTER) CONNECTOR DK BLU WIRE DK BLU/RED WIRE FOG FOG LAMP RELAY (IN POWER DIST CENTER) FUSE FUSE 12 FUSE 19 FUSE 7 FUSE BLOCK FUSE BLOCK FUSE 24 GRY/BLK WIRE HEADLAMP DIMMER SW (IN MULTI- FUNCTION SWITCH) HEADLAMP SWITCH HI-BEAM IND HOT AT ALL TIMES HOT IN RUN INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM (BRAKE WARNING) INSTRUMENT PANEL DIMMING/DRL MODULE (LEFT OF STEERING COLUMN, NEAR RELAY BANK) LEFT FOG LAMP RIGHT FOG LAMP LO HI LO RIGHT HEADLAMP LEFT HEADLAMP LO PARK LT BLU RED/ WIRE LT BLU/BLK WIRE LT GRN/BLK WIRE OFF ORG/ WIRE ORG/BLK WIRE ORG/VIO WIRE ORG/WHT WIRE PARK BRAKE SWITCH (ON BRAKE LEVER) PNK/ORG WIRE POWER DISTRIBUTION CENTER RED WIRE RED/GRY WIRE RED/LT BLU WIRE RED/ORG WIRE REOSATAT SWITCH TAN/BLK WIRE ULTRALIGHT SENTINEL CONNECTOR VEHICLE INFORMATION CENTER VEHICLE THEFT ALARM MODULE VEHICLE THEFT ALARM RELAY (IN RELAY CENTER) VIO WIRE VIO/ORG WIRE WHT WIRE YEL/DK GRN WIRE
