Jeep Cherokee II (1984-1996) up lock- out switch Wiring diagram
This page shows the only wiring diagram for the component.up lock- out switch, which is found in the car Jeep Cherokee II (1984-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram up lock- out switch (1 of 1)
1994 VFTC
BLK WIRE
BRN WIRE
BRN/WHT WIRE
CIRCUIT BREAKER 26
DK BLU/WHT WIRE
DK GRN/WHT WIRE
DN UP
FUSE BLOCK
GRY/BLK WIRE
HOT IN RUN
LEFT FRONT DOOR WINDOW MOTOR
LEFT REAR DOOR WINDOW MOTOR
LEFT REAR DOOR WINDOW SWITCH
LT BLU WIRE
MASTER POWER WINDOW SWITCH
POWER SUNROOF SYSTEM
RED/BLK WIRE
RIGHT FRONT DOOR WINDOW MOTOR
RIGHT FRONT DOOR WINDOW SWITCH
RIGHT REAR DOOR WINDOW MOTOR
RIGHT REAR DOOR WINDOW SWITCH
TAN WIRE
UP DN
UP LOCK- OUT SWITCH
VIO WIRE
VIO/WHT WIRE
WHT WIRE
YEL/GRY WIRE
Go to component -> Power window circuit -> UP LOCK- OUT SWITCH
