Jeep Cherokee II (1984-1996) trans fluid temp trans outpt spd sensor tcu batt/diag feed Wiring diagram

8 VOLT SUPPLY VSS INPUT BLK WIRE BLK/LT BLU WIRE BLK/RED WIRE BLK/YEL WIRE BRN/YEL WIRE COMPUTER DATA LINES DK BLU/BLK WIRE DK GRN/LT BLU WIRE FUSE FUSE GRY/LT BLU WIRE GRY/ORG WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT IN RUN OR START HTD REAR WDW/TRANS O/D SW ASSY (RIGHT POD) INSTRUMENT CLUSTER CONNECTOR LT BLU/BRN WIRE LT BLU/RED WIRE LT GRN WIRE LT GRN/ORG WIRE LT GRN/WHT WIRE MID- YEAR NP 231/242 TRANSFER CASE NP 249 TRANSFER CASE O/D SW, IND ORG/ WIRE ORG/BLK WIRE ORG/DK BLU WIRE PNK WIRE PNK/BLK WIRE PNK/ORG WIRE POWER DISTRI- BUTION CENTER POWERTRAIN CONTROL MODULE (PCM) (RIGHT REAR OF ENGINE COMPARTMENT) RED/WHT WIRE RED/YEL WIRE SENSOR GROUND SHAFT SPEED SENSOR (IN O/D GEAR CASE) TACHOMETER TAN/ORG WIRE THROTTLE POSITION SENSOR (ON THROTTLE BODY) TRANS FLUID TEMP TRANS OUTPT SPD SENSOR TCU BATT/DIAG FEED TRANS SOL FEED TRANS. DIAGNOSTIC CONNECTOR (BELOW STEERING COLUMN) TRANSFER CASE SW (ON LEFT SIDE OF TRANSFER CASE) TRANSMISSION CONTROL MODULE (TCM) (REAR OF I/P, LEFT OF STEERING COLUMN) TRANSMISSION SOLENOID PACK (IN TRANSMISSION) VEHICLE INFORMATION CENTER (LOWER PART OF CENTER CONSOLE) VEHICLE SPEED SENSOR (REAR OF TRANS) VIO WIRE VIO/BRN WIRE VIO/WHT WIRE WHT/BLK WIRE WHT/GRY WIRE WHT/ORG WIRE YEL/BLK WIRE
