Jeep Cherokee II (1984-1996) left turn relay Wiring diagrams

BLK WIRE BRN/LT GRN WIRE CIRCUIT BREAKER DK BLU/RED WIRE DK GRN WIRE LEFT TURN RELAY LT BLU WIRE LT GRN WIRE PNK WIRE RED WIRE RED/BLK WIRE RIGHT TURN RELAY STOP/TURN RELAY TAN WIRE TO EXTERIOR LIGHTS TRAILER TOW CONNECTOR WHT/TAN WIRE

AIRBAG SYSTEM CONTROL MODULE BLK WIRE BLK/LT GRN WIRE BLK/ORG WIRE BLK/PNK WIRE BLK/TAN WIRE CENTER HIGH MOUNT STOP LAMP ELECTRONIC CONTROL MODULE FLOOR CONSOLE ILLUM- INATION RADIO FUEL TANK LEVEL GAUGE SENDING UNIT INSTRUMENT CLUSTER LEFT BACK-UP LAMP LEFT FRONT DOOR JAMB SWITCH LEFT FRONT KEY SWITCH LEFT POWER MIRROR LEFT POWER SEAT SWITCH LEFT REAR DOOR JAMB SWITCH LEFT TAIL/ STOP LAMP LEFT TURN RELAY LEFT TURN SIGNAL LAMP LEFT SIDE MARKER LAMP LICENSE LAMP LIFTGATE AJAR SWITCH HEATED REAR WINDOW LIFTGATE KEY CYLINDER SWITCH LIFTGATE TO BODY CONNECTOR LT BLU/BLK WIRE MASTER WINDOW SWITCH NCA WIRE ORG/ WIRE OVER- HEAD CONSOLE RADIO, AMPLIFIER REAR WIPER MOTOR RIGHT BACK-UP LAMP RIGHT POWER SEAT SWITCH RIGHT REAR DOOR JAMB SWITCH RIGHT SIDE MARKER LAMP RIGHT TURN RELAY RIGHT TURN SIGNAL LAMP RIGHT TAIL/ STOP LAMP SEAT BELT SWITCH STOP/ TURN RELAY TRAILER TOW CONNECTOR VEHICLE INFORMATION CENTER

BLK WIRE BRN/LT GRN WIRE CIRCUIT BREAKER DK BLU/RED WIRE DK GRN WIRE LEFT TURN RELAY LT BLU WIRE LT GRN WIRE LT GRN/ORG WIRE PNK WIRE RED/BLK WIRE RED/WHT WIRE RIGHT TURN RELAY STOP/TURN RELAY TAN WIRE TAN/ORG WIRE TO EXTERIOR LIGHTS TRAILER TOW CONNECTOR WHT/TAN WIRE
