Jeep Cherokee II (1984-1996) left tail/ stop lamp left side marker lamp Wiring diagrams
This page contains all the electrical diagrams for the component. left tail/ stop lamp left side marker lamp, in which he is found in the car Jeep Cherokee II (1984-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left tail/ stop lamp left side marker lamp (1 of 2)
4.0L M/T ONLY
A/T SWITCH
AFTER MARKET TRAILER TOW CONNECTOR
AUTO
BACK-UP LAMP SWITCH (LEFT SIDE OF TRANSMISSION)
BACK-UP LAMPS
BLK WIRE
BLK/ORG WIRE
BRAKE CONTROL
BRAKE SYSTEM)
BRN/LT GRN WIRE
CENTER HIGH- MOUNT STOP LAMPS
COLUMN)
DK BLU WIRE
DK BLU/RED WIRE
DK GRN/WHT WIRE
ELECTRIC BRAKE
ELECTRONIC FLASHER
FUSE 1
FUSE 12
FUSE 16
FUSE 3
FUSE BLOCK- I/P
HAZARD SWITCH
HEADLAMP SWITCH
HOT AT ALL TIMES
HOT IN RUN
HOT IN START OR RUN
INPUT
INST CLUSTER
INSTRUMENT CLUSTER
LAMP OUTAGE MODULE (LEFT REAR QUARTER PANEL)
LEFT PARK LAMP
LEFT SIDE MARKER LAMP RIGHT TURN LAMP
LEFT TAIL/ STOP LAMP LEFT SIDE MARKER LAMP
LEFT TURN INDICATOR
LEFT TURN LAMP
LEFT TURN SIGNAL LAMP
LICENSE LAMPS
LO/FOG
LT BLU WIRE
LT BLU/BLK WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT RT TURN SIGNAL SWITCH
MULTI- FUNCTION
NOT USED
OFF PARK
OFF SWITCH (ON STEERING
ON OFF
OPTIONAL
PNK/BLK WIRE
PNK/ORG WIRE
PNK/WHT WIRE
POWER ANTENNA
POWER DISTRIBUTION CENTER
POWER MIRRORS
RED/BLK WIRE
RED/TAN WIRE
RED/YEL WIRE
RIGHT PARK LAMP RIGHT SIDE MARKER LAMP
RIGHT SIDE MARKER LAMP
RIGHT TAIL/ STOP LAMP
RIGHT TURN INST CLUSTER (VEHICLE INFO. CENTER) INDICATOR
RIGHT TURN LAMP
RIGHT TURN SIGNAL LAMP
TAN WIRE
TAN/DK BLU WIRE
TO TRAILER TOW RELAYS
TRAILER GROUND
TRAILER POWER
VIO/TAN WIRE
WHT/BLK WIRE
WHT/TAN WIRE
YEL/DK GRN WIRE
Go to component -> Exterior light circuit, with lamp outage -> LEFT TAIL/ STOP LAMP LEFT SIDE MARKER LAMP
Wiring diagram left tail/ stop lamp left side marker lamp (2 of 2)
4.0L M/T ONLY
A/T SWITCH
AUTO
BACK-UP LAMP SWITCH (LEFT SIDE OF TRANSMISSION)
BACK-UP LAMPS
BLK WIRE
BLK/ORG WIRE
BRAKE CONTROL
BRAKE SYSTEM)
BRN/LT GRN WIRE
CENTER HIGH- MOUNT STOP LAMPS
COLUMN)
DK BLU WIRE
DK BLU/RED WIRE
DK GRN/WHT WIRE
ELECTRIC BRAKE
ELECTRONIC FLASHER
FUSE 1
FUSE 12
FUSE 16
FUSE 3
FUSE BLOCK- I/P
HAZARD SWITCH
HEADLAMP SWITCH
HOT AT ALL TIMES
HOT IN RUN
HOT IN START OR RUN
INPUT
INST CLUSTER
INSTRUMENT CLUSTER
LEFT PARK LAMP
LEFT SIDE MARKER LAMP RIGHT TURN LAMP
LEFT TAIL/ STOP LAMP LEFT SIDE MARKER LAMP
LEFT TURN INDICATOR
LEFT TURN LAMP
LEFT TURN SIGNAL LAMP
LICENSE LAMPS
LO/FOG
LT BLU WIRE
LT BLU/BLK WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT RT TURN SIGNAL SWITCH
MULTI- FUNCTION
NOT USED
OFF PARK
OFF SWITCH (ON STEERING
ON OFF
PNK/BLK WIRE
PNK/ORG WIRE
PNK/WHT WIRE
POWER ANTENNA
POWER DISTRIBUTION CENTER
POWER MIRRORS
RED/BLK WIRE
RED/TAN WIRE
RED/YEL WIRE
RIGHT BACK-UP LAMP LEFT BACK-UP LAMP
RIGHT PARK LAMP RIGHT SIDE MARKER LAMP
RIGHT SIDE MARKER LAMP
RIGHT TAIL/ STOP LAMP
RIGHT TURN INST CLUSTER (VEHICLE INFO. CENTER) INDICATOR
RIGHT TURN LAMP
RIGHT TURN SIGNAL LAMP
TAN WIRE
TAN/DK BLU WIRE
TO TRAILER TOW RELAYS
TRAILER GROUND
TRAILER POWER
VIO/TAN WIRE
WHT/BLK WIRE
WHT/TAN WIRE
YEL/DK GRN WIRE
Go to component -> Exterior light circuit, without lamp outage -> LEFT TAIL/ STOP LAMP LEFT SIDE MARKER LAMP
