Jeep Cherokee II (1984-1996) left tail/ stop lamp left back- up lamp Wiring diagrams
This page contains all the electrical diagrams for the component. left tail/ stop lamp left back- up lamp, in which he is found in the car Jeep Cherokee II (1984-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left tail/ stop lamp left back- up lamp (1 of 2)
ANTI-LOCK BRAKES SYSTEM
BACK-UP LAMP SWITCH (IN TRANSMISSION)
BLK WIRE
BLK/ORG WIRE
BLOCK
BRAKE SWITCH (ON BRAKE
BRN/LT GRN WIRE
CENTER HIGH- MOUNT STOP LAMPS
CHIME MODULE
COLUMN)
DEFOGGER SYSTEM
DK BLU/RED WIRE
DK BLU/WHT WIRE
DK GRN WIRE
FUSE 15
FUSE 8
FUSE BLOCK
HAZARD FLASHER
HAZARD SWITCH
HEAD OFF
HEADLAMP SWITCH
HOT AT ALL TIMES
HOT IN ACCY OR RUN
INSTRUMENT CLUSTER
LEFT FRONT PARK/TURN LAMP
LEFT SIDE MARKER LAMP
LEFT SIDE MARKER LAMP LEFT TURN LAMP
LEFT TAIL/ STOP LAMP LEFT BACK- UP LAMP
LEFT TURN INDICATOR
LICENSE LAMP
LT GRN WIRE
LT GRN/BLK WIRE
M/T ONLY
MULTI- FUNCTION
NOT USED
OFF
OFF ON
OFF SWITCH (ON STEERING
PARK DIMMER SWITCH
PNK/BLK WIRE
POWER DISTRIBUTION
REV
RIGHT BACK-UP LAMP RIGHT TAIL/ STOP LAMP
RIGHT FRONT PARK/TURN LAMP
RIGHT SIDE MARKER LAMP
RIGHT TURN INDICATOR
RIGHT TURN LAMP
SUPPORT BRACKET)
TAN WIRE
TAN/DK GRN WIRE
TRANSMISSION RANGE SWITCH (IN TRANSMISSION)
TURN SIGNAL FLASHER
TURN SIGNAL SWITCH
VIO/TAN WIRE
WARNING SYSTEMS
WHT/TAN WIRE
YEL/RED WIRE
Go to component -> Exterior light circuit, without trailer tow -> LEFT TAIL/ STOP LAMP LEFT BACK- UP LAMP
Wiring diagram left tail/ stop lamp left back- up lamp (2 of 2)
3 4 TO TRAILER TOW RELAYS
ANTI-LOCK BRAKES SYSTEM
BACK-UP LAMP SWITCH (IN TRANS- MISSION)
BLK WIRE
BLK/ORG WIRE
BLOCK
BRAKE SWITCH (ON BRAKE
BRN/LT GRN WIRE
CENTER HIGH- MOUNT STOP LAMPS
CHIME MODULE
COLUMN)
DEFOGGER SYSTEM
DK BLU/RED WIRE
DK BLU/WHT WIRE
DK GRN WIRE
ELECTRONIC BRAKE PROVISIONAL CONNECTOR
FUSE 15
FUSE 8
FUSE BLOCK
HAZARD FLASHER
HAZARD SWITCH
HEAD OFF
HEADLAMP SWITCH
HOT AT ALL TIMES
HOT IN ACCY OR RUN
INSTRUMENT CLUSTER
LEFT FRONT PARK/TURN LAMP
LEFT SIDE MARKER LAMP LEFT TURN LAMP
LEFT TAIL/ STOP LAMP LEFT BACK- UP LAMP
LEFT TURN INDICATOR
LICENSE LAMP
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
M/T ONLY
MARKER LAMP
MULTI- FUNCTION
OFF
OFF ON
OFF SWITCH (ON STEERING
PARK DIMMER SWITCH
PNK/BLK WIRE
POWER DISTRIBUTION
RED WIRE
REV
RIGHT BACK-UP LAMP RIGHT TAIL/ STOP LAMP
RIGHT FRONT PARK/TURN LAMP
RIGHT SIDE MARKER LAMP
RIGHT TURN INDICATOR
RIGHT TURN LAMP
SUPPORT BRACKET)
TAN WIRE
TAN/DK GRN WIRE
TRANSMISSION RANGE SWITCH (IN TRANSMISSION)
TURN SIGNAL FLASHER
TURN SIGNAL SWITCH
VIO/TAN WIRE
WARNING SYSTEMS
WHT/TAN WIRE
YEL/RED WIRE
Go to component -> Exterior light circuit, with trailer tow (1 of 2) -> LEFT TAIL/ STOP LAMP LEFT BACK- UP LAMP
