Jeep Cherokee II (1984-1996) left door lock switch lock Wiring diagram

ARM BATTERY BLK WIRE BLK/ORG WIRE BLK/TAN WIRE BRN/TAN WIRE CCD BUSS (-) CIRCUIT BREAKER 27 DATA LINK CONNECTOR 2 DISARM DK BLU/RED WIRE DOOR JAMB DOOR LOCK B+ LOCK DOOR LOCK B+ UNLOCK FUSE 21 FUSE 6 FUSE 7 FUSE 8 FUSE BLOCK GROUND GRY/ORG WIRE HEADLAMP DIMMER SWITCH HEADLAMPS SECURITY INDICATOR HEADLAMPS SYSTEM (HI BEAMS) HOOD HOOD JAMB SWITCH HORN HORN RELAY (IN RELAY CENTER) HORNS SYSTEM (HORN SWITCH) HOT AT ALL TIMES HOT IN ACCY OR RUN HOT IN RUN OR START IGN/ACCY IGNITION INSTRUMENT CLUSTER INTERIOR LIGHTS SYSTEM (CARGO LAMP) INTERIOR LIGHTS SYSTEM (RIGHT COURTESY LAMP) KEYLESS ENTRY MODULE LEFT DOOR LOCK SWITCH LOCK LEFT FRONT DOOR JAMB SWITCH LEFT FRONT KEY SWITCH (PART OF DOOR HANDLE) LEFT REAR DOOR JAMB SWITCH LIFTGATE LIFTGATE AJAR LIFTGATE KEY CYLINDER SWITCH LOCK LT GRN/BLK WIRE LT GRN/RED WIRE ORG/ WIRE ORG/VIO WIRE PARK/TAIL LAMPS PNK WIRE PNK/ POWER DOOR UNLOCK RELAY WIRE PNK/ORG WIRE PNK/VIO WIRE POWER DISTRIBUTION SYSTEM POWER DOOR LOCK RELAY REAR WIPER MOTOR RED/ORG WIRE RED/WHT WIRE RIGHT DOOR LOCK SWITCH RIGHT FRONT DOOR JAMB SWITCH RIGHT FRONT KEY SWITCH (PART OF DOOR HANDLE) RIGHT REAR DOOR JAMB SWITCH SECURITY INDICATOR TAN/BLK WIRE TAN/PNK WIRE UNLOCK VEHICLE INFORMATION CENTER (LOWER PART OF CENTER CONSOLE) VEHICLE THEFT ALARM MODULE (RIGHT REAR SIDE OF I/P) VEHICLE THEFT ALARM RELAY (IN RELAY CENTER) VIO WIRE VIO/BRN WIRE VIO/YEL WIRE WHT/BLK WIRE WHT/GRY WIRE YEL WIRE
