Jeep Cherokee II (1984-1996) left dash panel speaker Wiring diagram
This page shows the only wiring diagram for the component.left dash panel speaker, which is found in the car Jeep Cherokee II (1984-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left dash panel speaker (1 of 1)
ANT INPUT
ANT. GRND
BLK WIRE
BRN/LT BLU WIRE
BRN/RED WIRE
BRN/YEL WIRE
DK BLU WIRE
DK BLU/ORG WIRE
DK BLU/PNK WIRE
DK BLU/RED WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/RED WIRE
FUSE 1
FUSE 10
FUSE 24
FUSE 4
FUSE 8
FUSE BLOCK (UNDER RIGHT SIDE OF DASH)
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN RUN OR ACC
LEFT DASH PANEL SPEAKER
LEFT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER
LT BLU/BLK WIRE
LT BLU/RED WIRE
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/RED WIRE
NCA WIRE
ORG/ WIRE
POWER AMPLIFIER (BELOW LEFT REAR SEAT)
POWER ANTENNA MOTOR (IN RIGHT FRONT QUARTER PANEL)
POWER ANTENNA RELAY (IN RELAY CENTER UNDER GLOVE BOX)
RADIO
RED WIRE
RED/ BLK WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT DASH PANEL SPEAKER
RIGHT FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
TAN/BLK WIRE
TAN/RED WIRE
UP DN UP DN
VIO WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
WHT/RED WIRE
Go to component -> Radio circuits, premium model -> LEFT DASH PANEL SPEAKER
