Jeep Cherokee II (1984-1996) instrument panel dimming/ drl module ultralight sentinel Wiring diagram

AFTERMARKET TRAILER TOW HARNESS CONNECTOR BLK LT GRN/ WIRE BLK RED/ WIRE BLK WIRE BLK/LT BLU WIRE BLK/TAN WIRE BRAKE SWITCH CARGO LAMP CIRCUIT BREAKER CIRCUIT BREAKER 25 CIRCUIT BREAKER 28 DK BLU WIRE DK GRN RED/ WIRE ELECTRONIC FLASHER RELAY FROM FROM INTERIOR, EXTERIOR LIGHTING SYSTEMS (HEADLAMP SWITCH) FUSE 1 FUSE 12 FUSE 13 FUSE 14 FUSE 2 FUSE 23 FUSE 24 FUSE 3 FUSE 5 FUSE 8 FUSE 6 FUSE 7 FUSE BLOCK GLOVE BOX LAMP ILLUMINATED ENTRY RELAY RELAY CENTER HEADLAMP DIMMER SWITCH HEADLAMP SWITCH HEATED REAR WINDOW HEATED REAR WINDOW RELAY HEATER HEATER HEVAC CONTROL (W/ ATC) POWER MIRROR SWITCH HORN RELAY POWER DOOR LOCK RELAY IGNITION SWITCH LAMP INSTRUMENT CLUSTER INSTRUMENT PANEL DIMMING/ DRL MODULE ULTRALIGHT SENTINEL INTERIOR MIRROR (W/ POWER SUNROOF) KEYLESS ENTRY MODULE RIGHT DOOR LOCK SWITCH LEFT COURTESY LAMP (DOOR) LEFT DOOR LOCK SWITCH LEFT HAND COURTESY LAMP LEFT POWER SEAT SWITCH LIFTGATE LIGHTED VISOR DOME/ READING LAMPS LT BLU WIRE LT BLU YEL/ WIRE LT GRN/BLK WIRE MULTI- FUNCTION SWITCH ORG/ WIRE ORG/WHT WIRE OVERHEAD CONSOLE PNK WIRE PNK/ DK BLU WIRE PNK/ORG WIRE POWER ANTENNA RELAY POWER DISTRIBUTION CENTER POWER DOOR UNLOCK RELAY RADIO CHIME MODULE REAR WIPER MOTOR RED WIRE RED YEL/ WIRE RED/ BLK WIRE RED/ WHT WIRE RED/BLK WIRE RED/LT GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY CENTER RELAY CENTER HEATED REAR WINDOW RELAY RIGHT COURTESY LAMP (DOOR) RIGHT HAND COURTESY LAMP RIGHT POD RIGHT POWER SEAT SWITCH STOP/ TURN RELAY TRAILER TOW CONNECTOR (PARTIAL) (BASE) VEHICLE INFORMATION CENTER VEHICLE THEFT ALARM MODULE VEHICLE THEFT ALARM RELAY W/ AFTERMARKET TRAILER TOW PLUS TRAILER TOW W/ OVERHEAD CONSOLE OR POWER SUNROOF W/ SUNROOF W/ TRAILER TOW ONLY WHT RED/ WIRE WHT WIRE WITH AFTERMARKET TRAILER TOW ONLY YEL WIRE
