Jeep Cherokee II (1984-1996) in-line circuit breaker Wiring diagram
This page shows the only wiring diagram for the component.in-line circuit breaker, which is found in the car Jeep Cherokee II (1984-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram in-line circuit breaker (1 of 1)
1994 VFTC
B/H
BLK WIRE
BRN WIRE
FRONT WASHER PUMP MOTOR
FRONT WIPER MOTOR
GRY WIRE
HI HI OFF LO LO
HOT IN ACCY OR RUN
IN-LINE CIRCUIT BREAKER
LO HI
LT GRN WIRE
LT GRN/BLK WIRE
NCA WIRE
OFF
OFF ON
PARK SWITCH
PNK WIRE
REAR WASHER PUMP MOTOR (UNDER WASHER BOTTLE)
RED WIRE
RUN WIRE
TAN WIRE
VIO WIRE
WASHER SWITCH
WHT WIRE
WIPER SWITCH
WIPER/ WASHER SWITCH
YEL WIRE
