Jeep Cherokee II (1984-1996) headlamp dimmer, optical horn switch Wiring diagrams
This page contains all the electrical diagrams for the component. headlamp dimmer, optical horn switch, in which he is found in the car Jeep Cherokee II (1984-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram headlamp dimmer, optical horn switch (1 of 2)
BLK WIRE
BLK/ORG WIRE
BLK/TAN WIRE
BRIGHT HEAD
BRN/WHT WIRE
CHIME MODULE
DIM PARK
DK BLU WIRE
DK BLU/RED WIRE
DK BLU/YEL WIRE
FOG LAMP RELAY (INTERRUPT) (LEFT SIDE RADIATOR CLOSURE PANEL)
FOG LAMP RELAY (LEFT SIDE RADIATOR CLOSURE PANEL)
FOG LAMP SWITCH
FUSE
FUSE 11
FUSE 15
FUSE 17
FUSE 19
FUSE 4
FUSE BLOCK
GRY/PNK WIRE
HEAD- LAMP SWITCH
HEADLAMP DELAY MODULE (NEXT TO HEADLAMP SW)
HEADLAMP DIMMER, OPTICAL HORN SWITCH
HI LEFT HEADLAMP
HI-BEAM IND
HORN RELAY
HOT AT ALL TIMES
IGN OFF
IGNITION SWITCH
INSTRUMENT CLUSTER
LEFT FOG LAMP
LO (ON STEERING COLUMN) FLASH
LO HI HI
LO HI RIGHT HEADLAMP
LT BLU WIRE
LT BLU/BLK WIRE
OFF
OFF HEAD
ORG/DK GRN WIRE
PARK
PNK/LT GRN WIRE
POWER DISTRIBUTION CENTER
RED/ORG WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FOG LAMP
RUN WIRE
TAN/BLK WIRE
VEHICLE SPEED SENSOR
VIO/WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
WIPER SWITCH
YEL WIRE
Go to component -> Headlamps/fog lamps circuit, with drl -> HEADLAMP DIMMER, OPTICAL HORN SWITCH
Wiring diagram headlamp dimmer, optical horn switch (2 of 2)
BLK WIRE
BLK/ORG WIRE
BRIGHT HEAD
BRN/WHT WIRE
CHIME MODULE
DIM PARK
DK BLU/RED WIRE
FOG LAMP RELAY (INTERRUPT) (LEFT SIDE RADIATOR CLOSURE PANEL)
FOG LAMP RELAY (LEFT SIDE RADIATOR CLOSURE PANEL)
FOG LAMP SWITCH
FUSE
FUSE 11
FUSE 15
FUSE 17
FUSE 19
FUSE 4
FUSE BLOCK
GRY WIRE
GRY/PNK WIRE
HEAD- LAMP SWITCH
HEADLAMP DELAY MODULE (NEXT TO HEADLAMP SW)
HEADLAMP DIMMER, OPTICAL HORN SWITCH
HI LO
HI-BEAM IND
HORN RELAY
HOT AT ALL TIMES
HOT IN RUN, START
IGN OFF
INSTRUMENT CLUSTER
LEFT FOG LAMP
LEFT HEADLAMP
LO (ON STEERING COLUMN) FLASH
LO HI FLASH
LO HI RIGHT HEADLAMP
LT BLU WIRE
OFF
OFF HEAD
ORG/DK GRN WIRE
PARK
PNK WIRE
PNK/LT GRN WIRE
POWER DISTRIBUTION CENTER
RED/ORG WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FOG LAMP
TAN/BLK WIRE
VIO/WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
WIPER SWITCH
YEL WIRE
Go to component -> Headlamps/fog lamps circuit, without drl -> HEADLAMP DIMMER, OPTICAL HORN SWITCH
