Jeep Cherokee II (1984-1996) electronic flasher relay relay center Wiring diagram
This page shows the only wiring diagram for the component.electronic flasher relay relay center, which is found in the car Jeep Cherokee II (1984-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electronic flasher relay relay center (1 of 1)
1994 VFTC
ABS SYSTEM RELAY
AIRBAG SYSTEM CONTROL MODULE
BLK ORG/ WIRE
BLK WIRE
BLK/ WHT WIRE
BLK/WHT WIRE
BRN/PNK WIRE
CHIME MODULE ULTRALIGHT SENTINEL
CIGAR LIGHTER
CIRCUIT BREAKER 26
CIRCUIT BREAKER 27
CRUISE CONTROL SWITCH
DK BLU RED/ WIRE
DK BLU WIRE
DK BLU/ YEL WIRE
DK BLU/GRY WIRE
DK BLU/YEL WIRE
DK GRN PNK/ WIRE
DK GRN/ YEL WIRE
ELECTRONIC CONTROL MODULE
ELECTRONIC FLASHER RELAY RELAY CENTER
ENGINE STARTER RELAY
FROM
FROM POWER DISTRIBUTION CENTER
FUSE 10
FUSE 11
FUSE 15
FUSE 16
FUSE 17 FUSE 18
FUSE 19
FUSE 20
FUSE 21
FUSE 22
FUSE 4
FUSE 9
FUSE BLOCK
GRY WIRE
HEATED REAR WINDOW RELAY
HEATED REAR WINDOW/ TRANSMISSION OVERDRIVE SWITCH ASSEMBLY
HEVAC SWITCHES
HEVAC SWITCHES AIR MIX SERVO MOTOR FRESH AND RECIRCULATION SERVO MOTOR
IGNITION SWITCH
INSTRUMENT CLUSTER
INTERIOR MIRROR (WITHOUT POWER SUNROOF)
LT GRN/RED WIRE
LT GRN/YEL WIRE
MULTI- FUNCTION SWITCH
OFF
ORG/BLK WIRE
OVERHEAD CONSOLE KEYLESS ENTRY MODULE
OVERHEAD CONSOLE MASTER WINDOW SWITCH
PNK WIRE
PNK/ DK GRN WIRE
POWER DISTRIBUTION CENTER
RADIO
RADIO, AMPLIFIER
REAR WIPER/ WASHER SWITCH
RED WIRE
RED/GRY WIRE
RED/TAN WIRE
RELAY CENTER
RIGHT POD
RUN WIRE
SUNROOF CONTROL MODULE
SUNROOF SWITCH
TAN WIRE
TO FUSES
VEHICLE INFORMATION CENTER
VEHICLE THEFT ALARM MODULE LAMP OUTAGE MODULE (OPTIONAL)
VIO WIRE
W/O ATC W/ ATC
WHT WIRE
WHT/RED WIRE
WIPER/ WASHER SWITCH VEHICLE THEFT ALARM MODULE
YEL DK BLU/ WIRE
YEL DK GRN/ WIRE
YEL WIRE
YEL/DK GRN WIRE
Go to component -> Power distribution circuit (2 of 3) -> ELECTRONIC FLASHER RELAY RELAY CENTER
