Jeep Cherokee II (1984-1996) courtesy lamp switch wiring diagram
This page shows the only wiring diagram for the component.courtesy lamp switch, which is found in the car Jeep Cherokee II (1984-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
courtesy lamp switch wiring diagram (1 of 1)
ASHTRAY LAMP
AUTO HEADLAMP MODULE
AUTO OFF
BATTERY
BLK WIRE
CANCEL SWITCH
CIGAR LIGHTER LAMP
COURTESY LAMP SWITCH
DIM OUTPUT
DK BLU/RED WIRE
FLOOR CONSOLE LAMP
FOG HEAD PARK
FUSE BLOCK FUSE 12
FUSE BLOCK FUSE 24
GROUND
HEADLAMP SWITCH
HEATED REAR WINDOW/ TRANSMISSION OVERDRIVE SWITCH ASSEMBLY
HEVAC CONTROLLER
HOT AT ALL TIMES FUSE
ILLUM
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMING/ DRL MODULE (LEFT OF STEERING COLUMN, NEAR RELAY BANK)
LEFT FRONT DOOR JAMB SWITCH
LIGHTS ON
MANUAL A/C
ORG/ WIRE
ORG/BLK WIRE
ORG/VIO WIRE
ORG/WHT WIRE
OVERHEAD CONSOLE
PNK/ORG WIRE
POWER DISTRIBUTION CENTER
RADIO
RED/LT BLU WIRE
REOSTAT
VEHICLE INFORMATION CENTER HEVAC SWITCH
YEL WIRE
Go to component -> Interior light circuit (2 of 2) -> COURTESY LAMP SWITCH
