Jeep Cherokee II (1984-1996) chime module Wiring diagrams
This page contains all the electrical diagrams for the component. chime module, in which he is found in the car Jeep Cherokee II (1984-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
chime module wiring diagram (1 of 5)
ANTI-LOCK BRAKES SYSTEM
BACK-UP LAMP SWITCH (IN TRANSMISSION)
BLK WIRE
BLK/ORG WIRE
BLOCK
BRAKE SWITCH (ON BRAKE
BRN/LT GRN WIRE
CENTER HIGH- MOUNT STOP LAMPS
CHIME MODULE
COLUMN)
DEFOGGER SYSTEM
DK BLU/RED WIRE
DK BLU/WHT WIRE
DK GRN WIRE
FUSE 15
FUSE 8
FUSE BLOCK
HAZARD FLASHER
HAZARD SWITCH
HEAD OFF
HEADLAMP SWITCH
HOT AT ALL TIMES
HOT IN ACCY OR RUN
INSTRUMENT CLUSTER
LEFT FRONT PARK/TURN LAMP
LEFT SIDE MARKER LAMP
LEFT SIDE MARKER LAMP LEFT TURN LAMP
LEFT TAIL/ STOP LAMP LEFT BACK- UP LAMP
LEFT TURN INDICATOR
LICENSE LAMP
LT GRN WIRE
LT GRN/BLK WIRE
M/T ONLY
MULTI- FUNCTION
NOT USED
OFF
OFF ON
OFF SWITCH (ON STEERING
PARK DIMMER SWITCH
PNK/BLK WIRE
POWER DISTRIBUTION
REV
RIGHT BACK-UP LAMP RIGHT TAIL/ STOP LAMP
RIGHT FRONT PARK/TURN LAMP
RIGHT SIDE MARKER LAMP
RIGHT TURN INDICATOR
RIGHT TURN LAMP
SUPPORT BRACKET)
TAN WIRE
TAN/DK GRN WIRE
TRANSMISSION RANGE SWITCH (IN TRANSMISSION)
TURN SIGNAL FLASHER
TURN SIGNAL SWITCH
VIO/TAN WIRE
WARNING SYSTEMS
WHT/TAN WIRE
YEL/RED WIRE
Go to component -> Exterior light circuit, without trailer tow -> CHIME MODULE
chime module wiring diagram (2 of 5)
3 4 TO TRAILER TOW RELAYS
ANTI-LOCK BRAKES SYSTEM
BACK-UP LAMP SWITCH (IN TRANS- MISSION)
BLK WIRE
BLK/ORG WIRE
BLOCK
BRAKE SWITCH (ON BRAKE
BRN/LT GRN WIRE
CENTER HIGH- MOUNT STOP LAMPS
CHIME MODULE
COLUMN)
DEFOGGER SYSTEM
DK BLU/RED WIRE
DK BLU/WHT WIRE
DK GRN WIRE
ELECTRONIC BRAKE PROVISIONAL CONNECTOR
FUSE 15
FUSE 8
FUSE BLOCK
HAZARD FLASHER
HAZARD SWITCH
HEAD OFF
HEADLAMP SWITCH
HOT AT ALL TIMES
HOT IN ACCY OR RUN
INSTRUMENT CLUSTER
LEFT FRONT PARK/TURN LAMP
LEFT SIDE MARKER LAMP LEFT TURN LAMP
LEFT TAIL/ STOP LAMP LEFT BACK- UP LAMP
LEFT TURN INDICATOR
LICENSE LAMP
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
M/T ONLY
MARKER LAMP
MULTI- FUNCTION
OFF
OFF ON
OFF SWITCH (ON STEERING
PARK DIMMER SWITCH
PNK/BLK WIRE
POWER DISTRIBUTION
RED WIRE
REV
RIGHT BACK-UP LAMP RIGHT TAIL/ STOP LAMP
RIGHT FRONT PARK/TURN LAMP
RIGHT SIDE MARKER LAMP
RIGHT TURN INDICATOR
RIGHT TURN LAMP
SUPPORT BRACKET)
TAN WIRE
TAN/DK GRN WIRE
TRANSMISSION RANGE SWITCH (IN TRANSMISSION)
TURN SIGNAL FLASHER
TURN SIGNAL SWITCH
VIO/TAN WIRE
WARNING SYSTEMS
WHT/TAN WIRE
YEL/RED WIRE
Go to component -> Exterior light circuit, with trailer tow (1 of 2) -> CHIME MODULE
chime module wiring diagram (3 of 5)
ABS PUMP MOTOR LEFT TURN SIGNAL LAMP LEFT PARK LAMP
AIR MIX SERVO MOTOR
ASH LAMP
BATTERY
BLK WIRE
BLK/TAN WIRE
BLOWER HIGH RELAY
BRAKE SWITCH
CHIME MODULE
CIGAR LIGHTER ILLUM- INATION
DATA LINK CONNECTOR 1
DATA LINK CONNECTOR 2
DOME/ READING LAMPS
ENGINE OIL LEVEL SENSOR
ENGINE STARTER RELAY
ENGLISH/ METRIC SWITCH
FRONT WASHER PUMP MOTOR
FRONT WIPER MOTOR
GENERATOR
GLOVE BOX LAMP)
HEADLAMP SWITCH INSTRUMENT CLUSTER
HEATED OXYGEN SENSOR
HEATED REAR WINDOW/TRANS- MISSION OVERDRIVE SWITCH ASSEMBLY
ILLUM- INATED ENTRY RELAY
INTER- MITTENT WIPER MODULE
INTERIOR MIRROR (W/O POWER SUNROOF)
KEYLESS ENTRY MODULE
LEFT HEAD- LAMP
LEFT LIGHTED VISOR
PCM GROUND
POWER ANTENNA RELAY
POWER DOOR UNLOCK RELAY ELECTRONIC FLASHER RELAY HEVAC SWITCH
POWER MIRROR SWITCH
POWER MODULE BLOWER MOTOR
POWERTRAIN CONTROL MODULE
REAR WASHER PUMP MOTOR
RIGHT FRONT DOOR JAMB SWITCH
RIGHT FRONT KEY SWITCH
RIGHT HORN LEFT HORN
RIGHT LIGHTED VISOR
RIGHT POWER MIRROR
SUNROOF CONTROL MODULE
TRANSFER CASE SWITCH
TRANSMISSION CONTROL MODULE
ULTRA- LIGHT SENTINEL
UNDER- HOOD LAMP
VEHICLE INFORMATION CENTER CIGAR LIGHTER
VEHICLE THEFT ALARM MODULE
VEHICLE THEFT ALARM RELAY HEATED REAR WINDOW RELAY
VIO/WHT WIRE
W/ OVERHEAD CONSOLE
WASHER LEVEL SENSOR
WITH ATC WITHOUT ATC
WITH SUNROOF
Go to component -> Ground distribution circuit (1 of 2) -> CHIME MODULE
chime module wiring diagram (4 of 5)
BLK WIRE
BLK/ORG WIRE
BLK/TAN WIRE
BRIGHT HEAD
BRN/WHT WIRE
CHIME MODULE
DIM PARK
DK BLU WIRE
DK BLU/RED WIRE
DK BLU/YEL WIRE
FOG LAMP RELAY (INTERRUPT) (LEFT SIDE RADIATOR CLOSURE PANEL)
FOG LAMP RELAY (LEFT SIDE RADIATOR CLOSURE PANEL)
FOG LAMP SWITCH
FUSE
FUSE 11
FUSE 15
FUSE 17
FUSE 19
FUSE 4
FUSE BLOCK
GRY/PNK WIRE
HEAD- LAMP SWITCH
HEADLAMP DELAY MODULE (NEXT TO HEADLAMP SW)
HEADLAMP DIMMER, OPTICAL HORN SWITCH
HI LEFT HEADLAMP
HI-BEAM IND
HORN RELAY
HOT AT ALL TIMES
IGN OFF
IGNITION SWITCH
INSTRUMENT CLUSTER
LEFT FOG LAMP
LO (ON STEERING COLUMN) FLASH
LO HI HI
LO HI RIGHT HEADLAMP
LT BLU WIRE
LT BLU/BLK WIRE
OFF
OFF HEAD
ORG/DK GRN WIRE
PARK
PNK/LT GRN WIRE
POWER DISTRIBUTION CENTER
RED/ORG WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FOG LAMP
RUN WIRE
TAN/BLK WIRE
VEHICLE SPEED SENSOR
VIO/WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
WIPER SWITCH
YEL WIRE
Go to component -> Headlamps/fog lamps circuit, with drl -> CHIME MODULE
chime module wiring diagram (5 of 5)
BLK WIRE
BLK/ORG WIRE
BRIGHT HEAD
BRN/WHT WIRE
CHIME MODULE
DIM PARK
DK BLU/RED WIRE
FOG LAMP RELAY (INTERRUPT) (LEFT SIDE RADIATOR CLOSURE PANEL)
FOG LAMP RELAY (LEFT SIDE RADIATOR CLOSURE PANEL)
FOG LAMP SWITCH
FUSE
FUSE 11
FUSE 15
FUSE 17
FUSE 19
FUSE 4
FUSE BLOCK
GRY WIRE
GRY/PNK WIRE
HEAD- LAMP SWITCH
HEADLAMP DELAY MODULE (NEXT TO HEADLAMP SW)
HEADLAMP DIMMER, OPTICAL HORN SWITCH
HI LO
HI-BEAM IND
HORN RELAY
HOT AT ALL TIMES
HOT IN RUN, START
IGN OFF
INSTRUMENT CLUSTER
LEFT FOG LAMP
LEFT HEADLAMP
LO (ON STEERING COLUMN) FLASH
LO HI FLASH
LO HI RIGHT HEADLAMP
LT BLU WIRE
OFF
OFF HEAD
ORG/DK GRN WIRE
PARK
PNK WIRE
PNK/LT GRN WIRE
POWER DISTRIBUTION CENTER
RED/ORG WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT FOG LAMP
TAN/BLK WIRE
VIO/WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
WIPER SWITCH
YEL WIRE
Go to component -> Headlamps/fog lamps circuit, without drl -> CHIME MODULE
