Jeep Cherokee II (1984-1996) ant gnd Wiring diagram
This page shows the only wiring diagram for the component.ant gnd, which is found in the car Jeep Cherokee II (1984-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ant gnd (1 of 1)
ANT GND
ANT INPUT
BLK WIRE
BLU WIRE
BRN/LT BLU WIRE
BRN/RED WIRE
BRN/YEL WIRE
DK BLU WIRE
DK BLU/ORG WIRE
DK BLU/PNK WIRE
DK BLU/RED WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/RED WIRE
FUSE 10
FUSE 8
FUSE BLOCK
GRY WIRE
HOT AT ALL TIMES
HOT IN ACC OR RUN
LEFT FRONT DOOR SPEAKER
LEFT REAR DOOR SPEAKER
NCA WIRE
ORG/ WIRE
POWER ANTENNA MOTOR
POWER ANTENNA SYSTEM (POWER ANTENNA RELAY)
RADIO
RED WIRE
RED/GRY WIRE
RED/WHT WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT REAR DOOR SPEAKER
VIO WIRE
VIO/YEL WIRE
WHT WIRE
Go to component -> Radio circuits, base radio -> ANT GND
