Jeep Cherokee II (1984-1996) 4 5 16 17 key cyl alarm unlock rly lock rly Wiring diagram

4 5 16 17 KEY CYL ALARM UNLOCK RLY LOCK RLY 5 3 (1993) (1994) 5 3 (1994) (1993) BLK WIRE BLK/WHT WIRE CHIME MODULE (BEHIND INSTRUMENT CLUSTER) DK BLU/ORG WIRE FUSE 14 FUSE 19 FUSE 8 FUSE BLOCK HOT AT ALL TIMES HOT IN RUN INTERIOR LIGHTS SYSTEM (DOOR JAMB SWITCHES) INTERIOR LIGHTS SYSTEM (ILLUMINATED ENTRY RELAY) INTERIOR MIRROR KEYLESS ENTRY ENTRY LEFT DOOR LOCK SWITCH LEFT FRONT DOOR LOCK MOTOR LEFT REAR DOOR LOCK MOTOR LIFTGATE LOCK MOTOR LOCK LOCK UNLOCK MODULE (REAR OF OVERHEAD CONSOLE) ORG/VIO WIRE OVERHEAD CONSOLE PNK/BLK WIRE PNK/ORG WIRE PNK/VIO WIRE POWER DOOR LOCK RELAY (IN RELAY CENTER) POWER DOOR UNLOCK RELAY (IN RELAY CENTER) RED WIRE RED/WHT WIRE RIGHT DOOR LOCK SWITCH RIGHT FRONT DOOR LOCK MOTOR RIGHT REAR DOOR LOCK MOTOR UNLOCK VEHICLE THEFT ALARM MODULE (RIGHT SIDE REAR OF INSTRUMENT PANEL) VIO/YEL WIRE W/ OVERHEAD CONSOLE OR POWER SUNROOF W/O OVERHEAD CONSOLE, POWER SUNROOF YEL WIRE YEL/BLK WIRE YEL/DK GRN WIRE
