Jaguar XKR II facelift 2 (2011-2014) Shift interlock circuit

APPLY SW 1 RELEASE SW 1 HALL SUPPLY HALL SENS MOTOR POS AUXILIARY JUNCTION BOX (BEHIND REAR SEAT BACKREST) BATTERY JUNCTION BOX BLK WIRE BLU WIRE BRAKE SWITCH 1 BRN/GRN WIRE BRN/RED WIRE CENTRAL JUNCTION BOX (BEHIND LEFT KICK PANEL) COMPUTER DATA LINES SYSTEM ELECTRIC PARKING BRAKE (EPB) MODULE (BEHIND REAR SEAT BACKREST) FOOT BRAKE SWITCH FUSE (LEFT SIDE OF BATTERY) FUSE 18 FUSE 2 FUSE 8 GND RELEASE SW 2 GRN BRN/ WIRE GRN WIRE GRN/ORG WIRE GRN/WHT WIRE HOT AT ALL TIMES HS CAN NEG HS CAN POS SWITCH RTN BRK PEDAL SW IGN IGN HALL SIGNAL LOGIC BATT LOGIC GND MOTOR NEG ORG/ WIRE ORG/YEL WIRE PARKING BRAKE ACTUATOR (UNDER RIGHT REAR OF VEHICLE) RED/WHT WIRE TRANSMISSION SHIFT MODULE W/ ELECTRONIC REAR DIFFERENTIAL WHT WIRE YEL WIRE YEL/BLK WIRE
