Heated seats circuit for Jaguar XKR II facelift 2 (2011-2014)

BATTERY JUNCTION BOX BLK WIRE CENTRAL JUNCTION BOX (BEHIND LEFT KICK PANEL) CUSHION HEATERS DRIVER SEAT BACKREST HEATER DRIVER SEAT CUSHION HEATER DRV FRT SEAT FUSE (LEFT SIDE OF BATTERY) GREF HOT AT ALL TIMES HTR SENS HTR SPLY INTERNAL ELECTRONICS LOGIC GND PASS FRT SEAT PASSENGER SEAT BACKREST HEATER PASSENGER SEAT CUSHION HEATER RED WIRE RED/BLU WIRE THERMAL SENSOR WHT/BLK WIRE WHT/GRN WIRE
