Satellite radio circuit for Jaguar XKR II (2006-2008)

1 2 ANTENNA ANTENNA SCN BRAIDED 1 2 FIBER OPTIC FIBER OPTIC MOST RX MOST TX 1 2 VBATT GND AUXILIARY JUNCTION BOX BLK WIRE BRAIDED COMPUTER DATA LINES SYSTEM FUSE (BEHIND REAR SEAT BACKREST) HOT AT ALL TIMES NCA WIRE RED WIRE RED/GRN WIRE SDARS ANTENNA (IN LUGGAGE COMPT LID) SDARS TUNER MODULE SIG SCN YEL WIRE
