Jaguar XKR II (2006-2008) Door lock circuit

15 3 CAN - CAN + 3 15 CAN + CAN - AJAR SW AUXILIARY JUNCTION BOX (BEHIND REAR SEAT BACKREST) BLK WIRE BLU WIRE BRN/RED WIRE CAN (+) CENTRAL JUNCTION BOX (BEHIND LEFT KICK PANEL) CENTRAL LK COMPUTER DATA LINES SYSTEM DOOR AJAR SWITCH DOUBLE LK DRIVER DOOR SWITCH DRIVER'S DOOR LOCK ASSEMBLY DRIVER'S DOOR MODULE (IN DRIVER'S DOOR) FUEL FLAP RELEASE MOTOR FUSE 1 FUSE 13 GRN/BLU WIRE GRN/ORG WIRE HOT AT ALL TIMES LATCH GND LK COMMON LK FEEDBACK LK MTR LOGIC GND MTR OPEN NCA WIRE ORG/ WIRE ORG/YEL WIRE PASSENGER DOOR LOCK ASSEMBLY PASSENGER DOOR MODULE (IN PASSENGER'S DOOR) PASSENGER DOOR SWITCH POWER LOCK SWITCH POWER UNLOCK SWITCH PULL SW PULL SWITCH RED WIRE RED/BLU WIRE RED/WHT WIRE TRANSIST MODE BY-PASS CONNECTOR UNLK FEEDBACK WHT WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE
