Driver"s memory seat circuit for Jaguar XKR II (2006-2008)

AUTOGLIDE HALL GND TILT/SQB MTR HALL GND BLK WIRE BLU WIRE BRN WIRE BRN/GRN WIRE COMPUTER DATA LINES SYSTEM DEFLATE LOWER CELL DEFLATE UPPER CELL DRIVER BOLSTER SEAT SOLENOID DRIVER LUMBAR PUMP DRIVER LUMBAR VALVE BLOCK DRIVER SEAT MODULE (UNDER DRIVER'S SEAT) DRIVER SEAT SWITCH DRIVER SEAT TRACK SENSOR (BEHIND DRIVER GRN WIRE HGT/SLIDE/EXT MTR HALL EXTEND MTR SNS LUMBAR LO 1 INFLATE INFLATE LOWER CELL INFLATE UPPER CELL INLINE DIODE LIN LUMBAR HI 1 LUMBAR PUMP SOLENOID MS CAN OUT POS MS CAN OUT NEG ORG/ WIRE PNK DEFLATE WIRE PNK WIRE POWER POWER SEAT POWER SEAT) (IN DRIVER'S POWER SEAT) (UNDER DRIVER'S SEAT) PUMP RED WIRE SEAT BACK) SEAT BACKREST) SOL + WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/RED WIRE

BLK WIRE BLU WIRE BLU/YEL WIRE BRN/GRN WIRE BRN/RED WIRE CENTRAL JUNCTION BOX (BEHIND LEFT KICK PANEL) CUSHION RETRACT HEIGHT MTR UP HEIGHT MTR DOWN CUSHION EXTEND SLIDE MTR REARWARD DRIVER SEAT CUSHION EXTENSION MOTOR DRIVER SEAT MODULE (UNDER DRIVER'S SEAT) DRIVER SEAT SERVICE CONNECTOR DRIVER SEAT SLIDE MOTOR (UNDER DRIVER'S SEAT) DRIVER SEAT TILT MOTOR (UNDER DRIVER'S SEAT) DRIVER WINDOW MIRROR SWITCH DRIVERS SEAT HEIGHT MOTOR (UNDER DRIVER'S SEAT) FUSE 18 FUSE 30 FUSE 32 GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE HOT AT ALL TIMES LOGIC FEED NCA WIRE ORG/ WIRE ORG/GRN WIRE POWER FEED 1 POWER GND 1 POWER GND 2 LOGIC GND POWER FEED 2 RED WIRE RED/BLU WIRE RED/GRN WIRE SEAT RECLINE SQUAB MOTOR (BEHIND DRIVER SEAT BACKREST) SLIDE MTR (FORWARD) SQB MTR RECLINE SQB MTR INCLINE TILT MTR DOWN TILT MTR UP WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE YEL/BLU WIRE YEL/RED WIRE
