Jaguar XKR II (2006-2008) w/ trunk stack wiring diagram
This page shows the only wiring diagram for the component.w/ trunk stack, which is found in the car Jaguar XKR II (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
w/ trunk stack wiring diagram (1 of 1)
2 1 FIBER OPTIC FIBER OPTIC MOST TX MOST RX
FIBER OPTIC
FIBER OPTIC FIBER OPTIC 1 2 MOST RX MOST TX
FIBER OPTIC MOST RX
FIBER OPTIC MOST TX
FIBER OPTIC W/O TRUNK STACK
INFORMATION, ENTERTAINMENT CONTROL MODULE
INTEGRATED AUDIO MODULE
MOST TEST CONNECTOR (UNDER LEFT SIDE OF DASH) 2 1 FIBER OPTIC FIBER OPTIC
NAVIGATION SYSTEM MODULE
POWER AMPLIFIER (PASSENGER'S FOOTWELL)
SDARS TUNER MODULE
TELEPHONE MODULE (RIGHT SIDE OF LUGGAGE COMPT)
TOUCH SCREEN DISPLAY
W/ PREMIUM AUDIO
W/ TRUNK STACK
W/O PREMIUM AUDIO
Go to component -> Fibre optic network circuit -> W/ TRUNK STACK
