Charging circuit for Jaguar XKR I facelift (2004-2006)

11 25 CAN + CAN - 123 124 79 CAN - CAN + CHG WARN BATTERY (RIGHT SIDE OF TRUNK) BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM ENGINE COMPARTMENT FUSE BOX (LEFT FRONT OF ENGINE COMPT) ENGINE CONTROL MODULE (RIGHT REAR OF ENGINE COMPT) FALSE BULKHEAD STUD CONNECTOR (RIGHT SIDE OF FALSE BULKHEAD, IN ENGINE COMPT) FUSE 2 FUSE 22 GENERATOR (RIGHT FRONT OF ENGINE COMPT) GRN WIRE HIGH POWER PROTECTION MODULE (IN TRUNK, NEXT TO BATTERY) HOT AT ALL TIMES HOT IN RUN, START MAJOR INSTRUMENT PACK RED WIRE STARTER MOTOR (ENGINE BLOCK) TRUNK FUSE BOX (RIGHT SIDE OF TRUNK) WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE
