Power door locks circuit for Jaguar XKR I facelift (2004-2006)

1 5 6 8 9 16 17 B+ OUTPUT OUTPUT LOGIC GND DATA - DATA + PWR GND 5 20 INPUT INPUT BLK WIRE BLK/PNK WIRE BLU WIRE BODY PROCESSOR MODULE (BEHIND RIGHT SIDE OF DASH, ON AIR BAG BRACKET) BRN WIRE BRN/RED WIRE BRN/WHT WIRE DOOR LOCKING RELAY (NEAR PASSENGER SIDE FUSE BOX) DRIVER DOOR LOCK ACTUATOR (IN DRIVER DOOR) DRIVER SIDE FUSE BOX (LEFT SIDE OF DASH EXTERIOR HANDLE FUSE 15 FUSE 5 GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/WHT WIRE HOT AT ALL TIMES IGNITION SWITCH KEY IN LOCK STATUS NCA WIRE NOT-IN-PARK SWITCH (IN GEAR SELECTOR ASSEMBLY) OFF ORG/ WIRE PASSENGER DOOR AJAR SWITCH (IN PASSENGER DOOR) PASSENGER DOOR CONTROL MODULE (IN PASSENGER DOOR) PASSENGER DOOR LOCK ACTUATOR (IN PASSENGER DOOR) PASSENGER DOOR LOCK SWITCH (IN PASSENGER DOOR) PNK WIRE RED WIRE RED/GRN WIRE RUN WIRE VALET SWITCH WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/RED WIRE

1 2 REMOTE SIGNAL GROUND BRAIDED 4 5 12 20 INPUT INPUT INPUT INPUT 7 19 INPUT INPUT 8 13 14 15 16 DATA + GND GND B+ DATA - B+ OUTPUT OUTPUT LOGIC GND DATA - DATA + PWR GND BLK WIRE BLK/PNK WIRE BLU WIRE BRAIDED BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM COUPE DRIVER DOOR CONTROL MODULE (IN DRIVER DOOR) DRIVER DOOR LOCK SWITCHES (IN DRIVER DOOR) DRIVER'S DOOR AJAR SWITCH (IN DRIVER'S DOOR) EXTERIOR HANDLE FUSE 10 FUSE 15 FUSE 2 FUSE 4 GRN/BLU WIRE GRN/WHT WIRE HOT AT ALL TIMES KEY BARREL KEY FOB ANTENNA (TOP OF BACKLIGHT) LOCK ORG/YEL WIRE PASSENGER SIDE FUSE BOX (RIGHT SIDE OF DASH) PNK PNK WIRE PNK WIRE RED WIRE SECURITY, LOCKING CONTROL MODULE (IN TRUNK) TRUNK FUSE BOX (RIGHT SIDE OF TRUNK) UNLOCK WHT WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE
