Jaguar XKR I facelift (2004-2006) Defoggers circuit

4 18 5 OUTPUT OUTPUT OUTPUT AIR CONDITIONING CONTROL MODULE (ON RIGHT SIDE OF HVAC ASSEMBLY) BLK WIRE BLU WIRE BLU/YEL WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE DOOR MIRROR HEATER RELAY (BEHIND LEFT SIDE OF DASH, NEAR DRIVER SIDE FUSE BOX) DRIVER SIDE FUSE BOX (BEHIND LEFT SIDE OF DASH) DRIVER'S MIRROR FUSE 12 FUSE 16 FUSE 15 FUSE 17 FUSE 17 FUSE 2 FUSE 5 GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE HEATED BACKLIGHT HEATED REAR HOT AT ALL TIMES HOT IN RUN, START LEFT WINDSHIELD HEATER LEFT WINDSHIELD HEATER RELAY NCA WIRE ORG/ WIRE PASSENGER'S MIRROR RED WIRE RED/GRN WIRE RIGHT WINDSHIELD HEATER RIGHT WINDSHIELD HEATER RELAY TRUNK FUSE BOX (AT RIGHT SIDE OF TRUNK) WHT WIRE WHT/BLU WIRE WHT/RED WIRE YEL WIRE
