Anti-lock brakes circuit for Jaguar XKR I facelift (2004-2006)

ACTIVE BRAKE BOOSTER (NEAR BRAKE FLUID RESERVOIR) BLK WIRE BLK/PNK WIRE BLU WIRE BLU/YEL WIRE BRAKE BOOSTER SOLENOID BRAKE FLUID LEVEL SWITCH (IN FLUID RESERVOIR) BRAKE PRESSURE SENSOR (NEAR BRAKE FLUID RESERVOIR) BRK PRESS GND BRK PRESS SIG BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE CAN (+) CAN (-) CAN (+) CAN- CAN+ IGNITION CAN- GROUND CENTER CONSOLE SWITCH PACK COMPUTER DATA LINES SYSTEM CONTROL VALVES DRIVER SIDE FUSE BOX (BEHIND LEFT SIDE OF DASH) DSC IND GROUND DSC SWITCH DYNAMIC STABILITY CONTROL (DSC) CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) ENGINE COMPARTMENT FUSE BOX (LEFT FRONT OF ENGINE COMPT) FUSE 16 FUSE 18 FUSE 4 FUSE 6 GRN WIRE HOT AT ALL TIMES HOT IN RUN, START LEFT FRONT WHEEL SPEED SENSOR (LEFT FRONT WHEEL HUB ASSEMBLY) LEFT REAR WHEEL SPEED SENSOR (LEFT REAR WHEEL HUB ASSEMBLY) LF SPD SENSOR LF SPD SENSOR GROUND LINEAR SWITCH MODULE (UNDER CENTER CONSOLE, LEFT SIDE OF GEAR SELECTOR) LR SPD SENSOR LR SPD SENSOR DSC SWITCH NCA WIRE ORG/ WIRE PDL TRAVEL GND YR/LA SENSORS PDL TRAVEL SIG PEDAL FORCE SWITCH PEDAL TRAVEL SENSOR PRESSURE PUMP RED WIRE RED/WHT WIRE RIGHT FRONT WHEEL SPEED SENSOR (RIGHT FRONT WHEEL HUB ASSEMBLY) RIGHT REAR WHEEL SPEED SENSOR (RIGHT REAR WHEEL HUB ASSEMBLY) RR SPD SENSOR RR SPD SENSOR STATUS WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YAW RATE, LATERAL ACCELERATION SENSORS (UNDER CENTER CONSOLE) YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/RED WIRE
