Jaguar XKR I (1998-2004) Wiper/washer circuit

11000 OHMS 1300 OHMS 2700 OHMS 51000 OHMS 560 OHMS BLK WIRE BLK/GRN WIRE BLK/PNK WIRE BLU WIRE BLU/YEL WIRE BODY PROCESSOR MODULE (BEHIND RIGHT SIDE OF DASH, NEAR AIR BAG BRACKET) BRN WIRE BRN/GRN WIRE BRN/WHT WIRE COLUMN SWITCH GEAR DELAY 5100 OHMS DIP DRIVER'S SIDE FUSE BOX (BEHIND LEFT SIDE OF DASH) ENGINE COMPARTMENT FUSE BOX (IN LEFT FRONT OF ENGINE COMPARTMENT) FAST SLOW FAST WIPE FLICK WIPE FLUID LEVEL FUSE 3 FUSE 5 FUSE 7 GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE HOT AT ALL TIMES IGNITION SWITCH INTERMITTENT WIPE LIGHTING STALK LT GRN WIRE NCA WIRE OFF OFF (0) (III) ORG/ WIRE PARK SWITCH PNK WIRE POWER WASH RELAY (RELAY 4) POWERWASH PUMP (LEFT FRONT FENDER) RED WIRE RED/WHT WIRE RUN WIRE SIDE SLOW WIPE WASH WASH/WIPE STALK WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WINDSHIELD WASH PUMP, FLUID LEVEL SENSOR (IN WASHER RESERVOIR) WIPER FAST/ SLOW RELAY (LEFT REAR OF ENGINE COMPT) WIPER MOTOR (BASE OF WINDSHIELD, ON AIR INTAKE PLENUM) WIPER RUN/ STOP RELAY (LEFT REAR OF ENGINE COMPT) YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE

BLK WIRE BLK/GRN WIRE BLK/PNK WIRE BRN/WHT WIRE DRIVER'S SIDE FUSE BOX (BEHIND LEFT SIDE OF DASH) FUSE 16 GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE HOT IN RUN OR START INTERIOR REAR VIEW MIRROR PNK WIRE RAIN SENSING MODULE (ABOVE PASSENGER'S FOOTWELL) RAIN SENSOR (BEHIND INSIDE REAR VIEW MIRROR) RED WIRE RED/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/RED WIRE
