Charging circuit for Jaguar XKR I (1998-2004)
Charging circuit
BATTERY (RIGHT SIDE OF TRUNK)
BLK WIRE
BLU WIRE
CHARGE WARNING
ENGINE COMPARTMENT FUSE BOX (IN LEFT FRONT OF ENGINE COMPARTMENT)
FUSE 2
GENERATOR (RIGHT FRONT OF ENGINE COMPARTMENT)
HIGH POWER PROTECTION MODULE (IN TRUNK, NEXT TO BATTERY)
HOT IN RUN, START
MAJOR INSTRUMENT PACK
RED WIRE
STARTER MOTOR (ENGINE BLOCK)
SUPPRESSION MODULE (BEHIND RIGHT HEADLIGHT)
WHT WIRE
WHT/BLU WIRE
YEL WIRE
