Jaguar XK II facelift (2009-2011) Shift interlock circuit

APPLY SW 1 RELEASE SW 1 HALL SUPPLY HALL SENS MOTOR POS AUXILIARY JUNCTION BOX (BEHIND REAR SEAT BACKREST) BATTERY JUNCTION BOX (LEFT SIDE OF LUGGAGE COMPT) BLK WIRE BLU WIRE BRAKE SWITCH 1 BRN/GRN WIRE BRN/RED WIRE CENTRAL JUNCTION BOX (BEHIND LEFT KICK PANEL) COMPUTER DATA LINES SYSTEM FOOT BRAKE SWITCH FUSE FUSE 18 FUSE 2 FUSE 8 GND RELEASE SW 2 GRN BRN/ WIRE GRN WIRE GRN/ORG WIRE GRN/WHT WIRE HOT AT ALL TIMES HS CAN NEG HS CAN POS SWITCH RTN BRK PEDAL SW IGN HALL SIGNAL LOGIC BATT LOGIC GND MOTOR NEG ORG/ WIRE ORG/YEL WIRE PARKING BRAKE ACTUATOR (UNDER RIGHT REAR OF VEHICLE) PARKING BRAKE MODULE (BEHIND REAR SEAT BACKREST) RED/WHT WIRE TRANSMISSION SHIFT MODULE (BENEATH CENTER CONSOLE) W/ ELECTRONIC REAR DIFFERENTIAL WHT WIRE YEL WIRE YEL/BLK WIRE
