Jaguar XK II facelift (2009-2011) w/ vehicle information, communication system, w/ radio data system Wiring diagram
This page shows the only wiring diagram for the component.w/ vehicle information, communication system, w/ radio data system, which is found in the car Jaguar XK II facelift (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ vehicle information, communication system, w/ radio data system (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
FUEL FLAP RELEASE MOTOR
HIGH BOOT MOUNTED RELEASE STOP SWITCH LAMP
HIGH MOUNTED STOP LAMP SUPPRESSOR
IBOC RADIO SPLITTER MODULE SIGNAL (DIGITAL MODULE RADIO)
LEFT COMFORT SOLENOID
LEFT REAR NUMBER PLATE LAMP
LEFT REVERSE FOG LAMP
PARKING BRAKE MODULE
PASSENGER BUCKLE SWITCH
PASSENGER SEAT MODULE
PORTABLE AUDIO INTERFACE MODULE
RIGHT REAR LEFT TAIL NUMBER RIGHT TAIL LAMP PLATE LAMP UNIT UNIT LAMP
RIGHT REVERSE FOG LAMP
W/ NAVIGATION
W/ VEHICLE INFORMATION, COMMUNICATION SYSTEM, W/ RADIO DATA SYSTEM
W/O NAVIGATION
YEL WIRE
Go to component -> Ground distribution circuit (3 of 3) -> W/ VEHICLE INFORMATION, COMMUNICATION SYSTEM, W/ RADIO DATA SYSTEM
