Jaguar XK II facelift (2009-2011) stop lamp led array Wiring diagram
This page shows the only wiring diagram for the component.stop lamp led array, which is found in the car Jaguar XK II facelift (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stop lamp led array (1 of 1)
3 15 11 23 12 MS CAN POS MS CAN NEG COMPUTER DATA LINES SYSTEM
3 15 12 11 23 MS CAN POS MS CAN NEG COMPUTER DATA LINES SYSTEM
APPROACH LAMP SIDE TRN IND MIRROR GND
AUXILIARY JUNCTION BOX
B+ FOOT BRAKE HAZARD SW SIG SW
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
BRN/WHT WIRE
DI LED ARRAY
DRIVER SIDE DOOR MIRROR
DRIVER'S DOOR MODULE (IN DRIVER'S DOOR)
EARLY PRODUCTION
FUSE 1
FUSE 13
FUSE 21
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/ORG WIRE
HIGH MOUNTED STOP LAMP
HIGH MOUNTED SUPPRESSOR STOP LAMP
HMSL CTRL
HOT AT ALL TIMES
KL 31 GND
LATE PRODUCTION
LEFT REAR NUMBER PLATE LAMP
LEFT TAIL LAMP UNIT
LH STOP LAMP CTRL
LH TAIL
LR LED DI CTRL
NCA WIRE
NUMBER PLATE LAMP LAMPS CTRL CTRL
ORG/ WIRE
PASSENGER SIDE DOOR MIRROR
PASSENGER'S DOOR MODULE (IN PASSENGER'S DOOR)
RED WIRE
RH STOP LAMP CTRL
RH TAIL LAMP CTRL
RIGHT REAR NUMBER PLATE LAMP
RIGHT TAIL LAMP UNIT
SIDE MARKER LED ARRAY
SIDE TRN IND MIRROR GND APPROCH LAMP
STOP LAMP LED ARRAY
TAIL LAMP LED ARRAY
WHT WIRE
WHT/BLK WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> STOP LAMP LED ARRAY
