Jaguar XK II facelift (2009-2011) right tail lamp unit Wiring diagram

3 15 11 23 12 MS CAN POS MS CAN NEG COMPUTER DATA LINES SYSTEM 3 15 12 11 23 MS CAN POS MS CAN NEG COMPUTER DATA LINES SYSTEM APPROACH LAMP SIDE TRN IND MIRROR GND AUXILIARY JUNCTION BOX B+ FOOT BRAKE HAZARD SW SIG SW BLK WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/RED WIRE BRN/WHT WIRE DI LED ARRAY DRIVER SIDE DOOR MIRROR DRIVER'S DOOR MODULE (IN DRIVER'S DOOR) EARLY PRODUCTION FUSE 1 FUSE 13 FUSE 21 GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/ORG WIRE HIGH MOUNTED STOP LAMP HIGH MOUNTED SUPPRESSOR STOP LAMP HMSL CTRL HOT AT ALL TIMES KL 31 GND LATE PRODUCTION LEFT REAR NUMBER PLATE LAMP LEFT TAIL LAMP UNIT LH STOP LAMP CTRL LH TAIL LR LED DI CTRL NCA WIRE NUMBER PLATE LAMP LAMPS CTRL CTRL ORG/ WIRE PASSENGER SIDE DOOR MIRROR PASSENGER'S DOOR MODULE (IN PASSENGER'S DOOR) RED WIRE RH STOP LAMP CTRL RH TAIL LAMP CTRL RIGHT REAR NUMBER PLATE LAMP RIGHT TAIL LAMP UNIT SIDE MARKER LED ARRAY SIDE TRN IND MIRROR GND APPROCH LAMP STOP LAMP LED ARRAY TAIL LAMP LED ARRAY WHT WIRE WHT/BLK WIRE
