Jaguar XK II facelift (2009-2011) lf unlock sw rf unlock sw Wiring diagram
This page shows the only wiring diagram for the component.lf unlock sw rf unlock sw, which is found in the car Jaguar XK II facelift (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lf unlock sw rf unlock sw (1 of 1)
ANT NEG ANT POS R ANT NEG
ANT POS ANT NEG ANT NEG
AUXILIARY JUNCTION BOX (BEHIND REAR SEAT BACKREST)
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BOOT RELEASE SWITCH
CAN (+)
CENTRAL JUNCTION BOX (BEHIND LEFT KICK PANEL)
COMPUTER DATA LINES SYSTEM
CONVERTIBLE COUPE
GRN WIRE
HOT AT ALL TIMES
IN STATUS
KEYLESS VEHICLE MODULE (BEHIND RIGHT KICK PANEL)
LEFT FRONT CABIN FRONT ANTENNA
LF UNLOCK SW RF UNLOCK SW
LOCK PUSH SWITCH
LOCK PUSH SWITCH PASSENGER DOOR HANDLE
ORG/ WIRE
ORG/GRN WIRE
ORG/YEL WIRE
PULL SW
R ANT POS L ANT POS
REAR EXTERNAL LEFT FRONT ANTENNA (BEHIND CENTER OF REAR BUMPER)
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RELEASE SW
RELEASE SW LF LOCK SW
RF LOCK SW
START STOP GND
START/ STOP 1
START/ STOP 2
SW SENS START-STOP
TAILGATE INTERIOR ANTENNA (REAR OF LUGGAGE COMPARTMENT)
TRANSMISSION SHIFT MODULE (BENEATH CENTER CONSOLE)
UNLOCK PULL SWITCH
UNLOCK PULL SWITCH DRIVER DOOR HANDLE
WHT WIRE
YEL WIRE
Go to component -> Keyless entry circuit (1 of 2) -> LF UNLOCK SW RF UNLOCK SW
