Jaguar XK II facelift (2009-2011) left front tire sensor Wiring diagram
This page shows the only wiring diagram for the component.left front tire sensor, which is found in the car Jaguar XK II facelift (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front tire sensor (1 of 1)
16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 RF RTN RF PWR LF RTN LF PWR
16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 VBATT
AUXILIARY JUNCTION BOX (BEHIND REAR SEAT BACKREST)
BLK WIRE
BLU WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT KICK PANEL)
COMPUTER DATA LINES SYSTEM
DATA
ECU-B +B
EXT RF RX
FUSE 2
GND MS CAN + MS CAN -
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
LEFT FRONT INITIATOR (BEHIND LEFT FRONT WHEEL ARCH LINER)
LEFT FRONT TIRE SENSOR
LEFT REAR INITIATOR (BEHIND LEFT REAR WHEEL ARCH LINER)
LEFT REAR TIRE SENSOR
RED WIRE
RH RR RTN RH RR PWR LH RR RTN LH RR PWR
RIGHT FRONT INITIATOR (UNDER RIGHT FRONT OF VEHICLE)
RIGHT FRONT TIRE SENSOR
RIGHT REAR INITIATOR (BELOW RIGHT REAR WHEEL ARCH)
RIGHT REAR TIRE SENSOR
TIRE PRESSURE MONITORING CONTROL MODULE (BEHIND REAR SEAT BACKREST)
TIRE PRESSURE MONITORING RECEIVER (BEHIND REAR SEAT BACKREST)
VBATT
VIGN
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Tire pressure monitoring circuit -> LEFT FRONT TIRE SENSOR
