Jaguar XK II facelift (2009-2011) driver window driver mirror door switch switch Wiring diagram
This page shows the only wiring diagram for the component.driver window driver mirror door switch switch, which is found in the car Jaguar XK II facelift (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver window driver mirror door switch switch (1 of 1)
5.0L SC 5.0L
ABS MODULE
BLK WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE SWITCH 2
COOLING FAN CONTROL UNIT
DIAGNOSTIC CONNECTOR
DRIVER DOOR LATCH MODULE DRIVER DOOR HANDLE
DRIVER DOOR POWER MODULE AMPLIFIER
DRIVER WINDOW DRIVER MIRROR DOOR SWITCH SWITCH
ENGINE CONTROL MODULE (ECM)
FRONT ACCESSORY SOCKET
GLOVE COMPARTMENT SWITCH
HOOD AJAR SWITCH
HORNS
LEFT HEADLAMP
LOW WASHER FLUID LEVEL SENSOR
PEDESTRIAN PROTECTION MODULE
POWER AMPLIFIER COOLING FAN
RIGHT HEADLAMP
W/ ADAPTIVE
W/ PEDESTRIAN PROTECTION SYSTEM
W/ PREMIUM
WINDSCREEN POWER WASHER WASH PUMP PUMP
WINDSCREEN WIPER MOTOR
Go to component -> Ground distribution circuit (1 of 3) -> DRIVER WINDOW DRIVER MIRROR DOOR SWITCH SWITCH
