Jaguar XK II facelift (2009-2011) driver mirror window switch Wiring diagram

1 2 REAR QUARTER UP REAR QUARTER DOWN 15 3 MS CAN - MS CAN + 3 15 MS CAN + MS CAN - 3 6 PWR-2 POWER GND-2 9 10 CAN- CAN+ AUXILIARY JUNCTION BOX (BEHIND REAR SEAT BACKREST) BLK WIRE BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/GRN WIRE BRN/RED WIRE BRN/WHT WIRE CENTRAL JUNCTION BOX (BEHIND LEFT KICK PANEL) COMPUTER DATA LINES SYSTEM CONVERTIBLE TOP MODULE (BEHIND REAR SEAT BACKREST) DOWN DRIVER MIRROR WINDOW SWITCH DRIVER WINDOW MOTOR (AT CENTER OF DRIVER'S DOOR) DRIVER'S DOOR MODULE (IN DRIVER'S DOOR) FUSE GREEN GRN WIRE GRN/ORG WIRE HOT AT ALL TIMES LEFT REAR QUARTER WINDOW REGULATOR MOTOR (BEHIND LEFT REAR TRIM PANEL) LIN NCA WIRE ORG/GRN WIRE ORG/YEL WIRE PASSENGER DOOR MODULE (IN PASSENGER'S DOOR) PASSENGER DOOR SWITCH PACK PASSENGER SEAT SWITCH PASSENGER WINDOW MOTOR (AT CENTER OF PASSENGER'S DOOR) PWR RED WIRE RED/BLU WIRE RED/WHT WIRE RIGHT REAR QUARTER WINDOW REGULATOR MOTOR (BEHIND RIGHT REAR TRIM PANEL) SENS 1 SENS 2 SENS GND SNSR SPLY WHT WIRE WHT/GRN WIRE YEL/BLU WIRE
