Jaguar XK II facelift (2009-2011) 15 3 10 23 c- c+ mirr htr mirr gnd Wiring diagram
This page shows the only wiring diagram for the component.15 3 10 23 c- c+ mirr htr mirr gnd, which is found in the car Jaguar XK II facelift (2009-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 15 3 10 23 c- c+ mirr htr mirr gnd (1 of 1)
15 3 10 23 C- C+ MIRR HTR MIRR GND
2 13 B+ GND
B+ GND
B+ MS CAN C+
BATTERY JUNCTION BOX (LEFT SIDE OF LUGGAGE COMPT)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINES SYSTEM C+ C- MIRR HTR MIRR GND
COUPE
DRIVER DOOR MODULE
DRIVER SIDE DOOR MIRROR
FUSE
FUSE 1
FUSE 13
FUSE 23
HOT AT ALL TIMES
MS CAN C+
NCA WIRE
ORG/YEL WIRE
PASSENGER DOOR MODULE (IN PASSENGER'S DOOR)
PASSENGER SIDE DOOR MIRROR
REAR HEATED SCREEN RELAY
REAR SCREEN HEATER ELEMENT REAR WINDOW HEATER ELEMENT
RED WIRE
TRANSIT MODE BYPASS CONNECTOR
WHT WIRE
YEL WIRE
Go to component -> Rear defogger & heated mirrors circuit -> 15 3 10 23 C- C+ MIRR HTR MIRR GND
